41" X 300' 3mil Artshield Satinex UV Overlaminating Film (Semi-Gloss, 3" Core) - 1 Roll
FAQ: 0 Questions, 0 Answers
0 Q&As
Item# SX41300PP
- Thermal roll film
- 3mil laminate roll on 3" core
- Semi-gloss lamination finish
- Great for laminating at home or office for protected but flexible lamination
ProductDescription
This Artshield Satinex UV 41" x 300' Overlaminating Film is a 3mil Heatset PVC (vinyl) semi-gloss laminating film that provides excellent UV protection. The Artshield Satinex UV is perfect for enhancing posters, digital prints and photographs. This 41" x 300' Artshield Satinex UV can be applied in laminating fabrics, canvas, and raised surfaces such as leaves and dried flowers.
Item Specifications
- Finish: Semi-Gloss PVC
- Film Length: 300' (91m)
- Film Width: 41" (1041mm)
- Film Thickness: 3mil
- Base Film: 2.0mil (50 micron) PVC (vinyl)
- Adhesive: 1.0mil (25 micron) solvent acrylic
- Release Liner: Moisture stable paper
- Initial Tack: Low
- Application Temperature: 185°F-210°F (85°C-99°C)
- Dwell Time: 2-6 minutes
- Application: Fine Art Prints, Picture Framing/Photography, Plaque Mounting
- Part Number: SX41300PP
- Compatible Equipment: 3" Core Thermal Roll Laminators
Technical Data
Artshield Satinex is a 2 mil (50µ) UV stabilized, pre-perforated clear PVC laminating film with a semi-gloss finish, coated on one side with a heat activated solvent acrylic adhesive that is protected by a moisture stable bleached Kraft gridded release paper coated on one side with siliconized PE.
Typical Applications
Product Structure
Physical Characteristics
Process Settings
Typical Applications
- Enhances posters, digital prints and photographs.
- Ideal for laminating fabrics and canvas, and protecting raised surfaces, such as leaves and dried flowers.
Product Structure
| Film | Semi-Gloss Perforated PVC |
|---|---|
| Adhesive | Solvent Acrylic (Heat Activated) |
| Release Liner | 1 Side PE Coated Bleached Kraft Grid Paper (Moisture Stable) |
Physical Characteristics
| Film Thickness | 2 mil (50µ) |
|---|---|
| Adhesive Layer | 1 mil (25µ) |
| Film/Adhesive Ratio | 2:1 |
| UV Protection Factor | Film contains UV stabilizers, which prevent film degradation and provide UV protection to the underlying image |
| Outdoor Durability | Not Applicable |
| Service Temperature Range | -4°F to 203°F (-20°C to 95°C) |
| Peel Strength (20 min, FTM1) | 18 N/25mm |
| Shelf Life | Use within 1 year after opening original box |
| Storage Conditions | 59°F to 72°F (15°C to 22°C); 50 - 55% Relative Humidity |
Process Settings
| Equipment Type | Temperature | Dwell Time |
|---|---|---|
| Roller Laminator | Not recommended | |
| Press | 185°F to 210°F (85°C to 99°C) | 2-6 minutes |
