    Formax FD 2200-15 Data Integrity Scanning System
    25495.00 NewCondition InStock

    Formax FD 2200-15 Data Integrity Scanning System

    Part #: FD-2200-15
    Brand: Formax
    • Single-camera system for Output Scanning on tabletop inserters or pressure sealers.
    • Integrity and productivity reporting.
    • Sequence check (incrementing or decrementing).
    • Rated Speed: up to 40,000 items per hour.
    • Price Match Guarantee
    • Free Shipping

    $25,495.00

    Buy Now, Pay Later with financing options from $2,358/mo.Learn More >

    Qualifies for FREE Shipping!*

    SWIPE FOR MORE IMAGES
    • 0
    • 1

    Product Description

    The Formax FD 2200-15 Data Integrity Scanning System provides data integrity and print quality inspection for mail processing, secure printing and label inspection applications. The integrity software pulls together images and data collected from the single-camera system and allows the implementation of any number of software tools to read, control, inspect, verify, log and report. The Data Integrity Scanning System is ideal for use with select Formax Inserters and Production Pressure Sealers.

    Product Details

    • Single-camera system for Output Scanning on tabletop inserters or pressure sealers.
    • Integrity and productivity reporting.
    • Sequence check (incrementing or decrementing).
    • Rated Speed: up to 40,000 items per hour.
    • Report of all codes read.
    • Read:
      • OCR (Optical Character Recognition)
      • Barcode
      • Optional Dual Barcode & OCR Read
    • Verify:
      • Correct sequencing
      • Print File reconciliation
      • Identify duplicate and missing pieces
    • Log and Report:
      • 100% Proof of printing / mailing
      • Operator / job / production data
      • Detail, Error & Summary report
      • Includes date and time stamp of each read

    Product Reviews

    Write Your Own Review
    You're reviewing:Formax FD 2200-15 Data Integrity Scanning System
    Your Rating

    Item Specifications

    • Hardware & Software Included:
      • PC with monitor and keyboard
      • Camera
      • Brackets
      • Triggers
      • I/O’s
      • Stop circuits
      • Software
      • Single-camera driver
    • Supported Code Formats (OCR):
      • Fully font trainable by system operator
      • Skew: +/- 15 Deg
    • Barcode:
      • EAN 13
      • UPC A
      • Code 128
      • Code 93
      • 2/5 discrete
      • EAN 8
      • UPC E
      • Code 39
      • 2/5 interleaved
      • Pharmacode
    • Input Devices:
      • Area Scan Camera: Self-contained high resolution unit with field of view 2.75" x 3"
      • Triggering: Leading edge sensor, Encoder (5000ppr)
    • Processor:
      • Operating System: Windows XP
      • Process Time: Linear speeds in excess of 500 ft/min >50 reads per second
      • Chassis: Mini Tower, Power 110 - 230 VAC
      • Approvals: CE / UL Certified
    • Optional:
      • File look-up functionality
      • Both OCR and Barcode
