Accessories for Morgana DigiFold Pro XL Digital Creaser Folder
- Folds up to 6,000 A4 per hour / crease only - 7,500 per hour.
- Max loading capacity up to 7.9".
- Top fed vacuum feeder, ensures stable production for long runs.
- Fully automatic operator functions.
- Ships Free Over $75
$1,156.00
- 0
| Product Name | Item Number | Price | Qty | ||
|---|---|---|---|---|---|
| Additional Static Crease and Cross Perf Unit for Digifold Pro XL | 04PLDIGIFOLDPERF | $3,926.00
|
|||
| Standard DynaCrease Blade (1.2mm) for DigiFold Pro XL | 05PLDFPROXLSDB | $1,156.00
|
|||
| Narrow DynaCrease Blade (1.0mm) for DigiFold Pro XL | 05PLDFPROXLNDB | $1,156.00
|
|||
| Extra Narrow DynaCrease Blade (0.7mm) for DigiFold Pro XL | 05PLDFPROXLENDB | $1,156.00
|
Product Description
The DigiFold Pro XL is an automatic creasing and folding system designed for heavy-duty usage ideal for mid to high-volume digital offset production presses. It features a unique open-design suction feeder and a pull-out extension that handles stock sizes from 210 – 1300mm / 8.3’’ – 51’’ in length, the system complements the long sheet capabilities enabled in the production printers of today. Have a complete overview of the job in progress in the intuitive color touch screen where adjustments to crease and fold patterns can be made. Auto settings take care of the roller gap settings, speed adjustment, and fan settings, removing time-consuming adjustments of various settings. This advantage opens a wider range of applications such as covers for landscape booklets, book covers for oversized perfect bound books, multi-panel brochures, and many other applications made from these long sheets.
Product Details
- Folds up to 6,000 A4 per hour / crease only - 7,500 per hour.
- Max loading capacity up to 7.9".
- Top fed vacuum feeder, ensures stable production for long runs.
- Fully automatic operator functions. Key in sheet size, media type and thickness and the Pro XL will automatically set speed, roller gap and fan settings.
- A unique air knife system for sheet separation.
- Full cross perforation available, plus up to five inline perforation/scoring wheels.
- Up to 30 creases per sheet (static crease).
- Equipped with both a belt-stacker for folded sheets and a `delivery tray for crease only jobs.
Product Reviews
Item Specifications
- Max Loading Capacity: 200mm / 7.8" (100mm / 4" for sheet lengths above 700mm / 27.5")
- Max Paper Size W x L: 385mm / 15" x 700mm / 27.5" (385mm / 15" x 1300mm / 51" with extension table)
- Min Paper Size W x L: 93mm / 3.89" x 210mm / 8.25"
- Max Paper Thickness: 400gsm / 0.015"
- Min Paper Thickness: 80gsm / 0.0035"
- Max Sheets Per Hour: 6000 Sheets per hour, A4/half fold, one crease only 7,500. DynaCrease standard, Static crease optional
- Max Number of Creases Per Sheet: 30 (with optional static creasing tool)
- Min crease to Crease Distance: 0.1mm / 0.0039"
- Stacker Capacity: 120
- Footprint with Table Extension: 2765mm / 108.85" x 730mm / 28.74"
