Speed: Up to 16,450 forms per hour – based on 11" (279mm) Z-Fold
Hopper Capacity: Up to 500 forms 20#
Pre-Set Folds: Pre-programmed for C, V, Z in 11 - 17" forms, uneven C and Z 14" forms
Pre-Set Paper Sizes: FD Model: 11", 14", 17" / FE Model: A5, A4, A3, B6, B5, B4
ProductDescription
One-piece mailers have proven to be the most efficient and cost effective in sending postages, streamline your mail processing with AutoSeal FD2056. This table top pressure sealer is designed with productivity and user’s ease of use in mind. Processing at speeds of 16,450 sheets per hour, the sealer will have no trouble processing high demand outputs. The new full-color touchscreen, with internationally-recognized symbols, makes it quick and easy for almost anyone to use with little to no training. From the touch screen control panel, operators can browse through and select from the 5 pre-programmed standard folds that include even panel C, V, Z, and uneven/eccentric C and Z folds. Alternatively, users can also customize and store up to 35 custom fold settings. The sealer detects and adjusts for 11”, 14”, and 17” forms that no manual adjustments or separate settings are needed. Sealing process then starts in the drop-in three-roller feed system which automatically feeds forms with no fanning required, sheets then go through the integrated telescopic conveyor featuring automated nip roller positions. This automated process has simplified and shortened the sealing process that even untrained operators can run the machine little to no instruction. For storage an optional fully enclosed cabinet is available. To make operations even better, users may avail of 402 Series Joggers and the V-Stack36i Stacker that stacks of up to 22” of processed forms making it easier for operators to unload stacked output for further processing. Send out mailers in greater numbers and speed with AutoSeal FD2056.
Product Details
Operating Features
Fast!: Large jobs are processed quickly at speeds of up to 16,450 pieces per hour
Color Touchscreen Interface: A large full-color touchscreen control panel allows anyone to walk up and start processing forms in seconds
Drop-In Feed System: Three roller drop-in feed system produces dependable feeding of forms with no fanning required
17" Form Capability: Flexibility to process forms up to 17" in length
AutoStack™ Wheels: Fully-automated stacker wheels eliminate moving them by hand when switching form sizes and fold types
Integrated Telescoping Conveyor System: Conveyor can be set between 14" (356mm) and 36" (915mm) in length and holds up to 500 folded pieces
Noise Reduction: Top and side covers are insulated to reduce operating noise, and fold plates are completely enclosed
Fault Detector: Detects double feeding and any faults
6-Digit Resettable & 8-Digit Life Counters: Provides maximum audit control
AutoBatch™ Counter: Programmable to process pre-set number of forms into sets with a delay
Folding Features
Preset Folds in Common Paper Sizes: Pre-programmed for 5 popular fold types in 11 - 17" forms and uneven C and Z in 14" forms, totaling 11 programmed fold settings
Stores 35 Custom Folds: Up to 35 custom folds can be programmed and stored into memory
Standard Fold Settings Modification: Even the preset fold types can be modified individually for each paper size for maximum flexibility and customization
Technical Features
Adjustable Feed Table Pressure: Seven positions can be easily chosen to increase or decrease hopper tension to better feed thick and thin paper stocks
Seven-Point Fold Stops: Fold plates utilize seven point fold stops for crisp, accurate folds of large paper sizes at high speeds
Removable Roller Cover: Easily removed for improved access to sealer rollers and exit area
Easy-Off Feed Wheel Shaft: Feed wheels can be changed without removing side covers
Options
Locking Cabinet: Fully enclosed for storage
402 Series Jogger: Reduces static electricity and aligns forms for proper feeding
V-Stack36i Stacker: Vertically stacks up to 22" of folded documents, making them easier to unload
Item Specifications
Speed: Up to 16,450 forms per hour – based on 11" (279mm) Z-Fold
Hopper Capacity: Up to 500 forms 20#
Pre-Set Folds: Pre-programmed for C, V, Z in 11 - 17" forms, uneven C and Z 14" forms
Pre-Set Paper Sizes: FD Model: 11", 14", 17" / FE Model: A5, A4, A3, B6, B5, B4
Custom Folds: Stores up to 35 custom folds into memory
Paper Size: Min: 3.5" W x 5" L (88.9 W x 127 L mm) / Max: 12.25" W x 18" L (311 W x 457 L mm)
Usage: High-volume tabletop
Dimensions: Closed: 43" L x 21.28" W x 16" H (109 L x 54 W x 41 H cm) / Fully Extended: 55" L x 21.28" W x 16" H (140 L x 54 W x 41 H cm)
Weight: 127 lbs (97kg)
Power: 110-240VAC 50/60 Hz
Safety Certifications: UL & CE applied for
Made in the USA
Demonstration Video
Formax AutoSeal FD 2056 High-Volume Tabletop Pressure Sealer Demo Video
Transcript :
The Formax presents the FD 2056 touchscreen Pressure Sealer. The FD 2056 automatic Pressure Sealer provides the ultimate high volume tabletop solution for processing pressure sensitive one piece mailers, and is proudly made in the USA. Pressure seal forms can be used wherever a document can be printed and folded on one sheet, eliminating the cost of envelopes and creating a sealed mail ready piece. The FD 2056 is fully automated and features a full color touchscreen for quick and easy operation, the 2056 is fast processing up to 17,000 forms per hour with an integrated telescoping output conve ...
The Formax presents the FD 2056 touchscreen Pressure Sealer. The FD 2056 automatic Pressure Sealer provides the ultimate high volume tabletop solution for processing pressure sensitive one piece mailers, and is proudly made in the USA. Pressure seal forms can be used wherever a document can be printed and folded on one sheet, eliminating the cost of envelopes and creating a sealed mail ready piece. The FD 2056 is fully automated and features a full color touchscreen for quick and easy operation, the 2056 is fast processing up to 17,000 forms per hour with an integrated telescoping output conveyor capable of folding up to 500 processed forms at a time. User friendly features include the full color touchscreen, automatic fold settings that detect and adjust for various form sizes up to 11 by 17 inches, five pre programmed standard folds, the ability to store up to 36 custom fold settings and auto batch mode. The Auto batch mode is used to process a set of documents with a delay between each set for easy handling. The FD 2056, features a drop in feed system for dependable feeding forms with no paper fanning required, and an easy to use lever to adjust for different paper weights a variety of pressure seal. Forms can be processed in no time with just a few simple steps. Lower the feed tray and load printed press reseal forms. Press the fold, select icon to choose from one of five preprogrammed fold types. Press the one time button to process a single form for inspection. All set, adjust your speed and press Start to begin processing. Forms are folded, sealed and ready for the mail in a single pass. The FD 2056 advanced software allows for all standard fold types and paper sizes to be customized to meet your individual needs. The 2056 also includes a resettable six digit counter to keep an accurate count of forms processed. The patented telescoping conveyor stacker can be used in the closed position for tight spaces or fully extended to hold up to 500 folded and sealed forms, which reduces the frequency of unloading processed forms. In addition, the fully automated outfeed stacker wheels eliminate the need for manual adjustment when switching between form sizes and fold types. The FD 2056, is proudly made in the USA, offers proven technology and is an ideal solution for streamlining your pressure seal processing.
