The Formax AutoSeal FD 2300 Series Production Pressure Sealers are designed to handle the highest volume jobs with ease and dependability, with speeds of up to 43,000 forms per hour. Its user-friendly features include the graphics-based color touchscreen control panel, and the ability to program up to 200 custom jobs. The FD 2300 Series Pressure Sealers have fully automated settings that include the feeder, alignment rails, fold plate stops, deflectors and fold rollers, and delivery rollers. Versatility is key to the 2300 Series, which can process a variety of documents up to 11.5" wide and 25" long, including checks, invoices, school reports, tax forms, PIN notices and direct marketing pieces. In addition to the 20 standard pre-set folds, operators can program and store up to 200 custom jobs.
Four models are available to choose from which offer different in-feed options: the FD 2300 utilizes an air-feed system with a capacity of up to 500 forms; the FD 2300-EX offers an extended air-feed system to reach a capacity of up to 1,000 forms; the FD 2350 utilizes a pile-feed system to reach a total capacity of up to 3,500 loaded forms; and the FD 2380 works in-line with the Formax FD 676 Maxi Burster for processing continuous forms.
With the help of the optional Formax V-Stack36 Vertical Stacker (sold separately), you can stack up to 22" of processed forms, making them easier to unload for further handling.
All of the four models above produce fast and accurate folds for secure and time-effective finished product ready for the mail. With the awesome features above, the Formax AutoSeal FD 2300 Series Production Pressure Sealers clearly sets the new standard for high volume processing.
Product Details
High-Speed Processing: Large jobs are processed quickly at speeds of up to 45,000 pieces per hour.
Various Form Sizes: Handles a variety of documents up to 11.5" wide and 25" long.
Versatile: Processes forms including checks, invoices, school reports, tax forms, appointment notices, PIN notices and a variety of direct marketing pieces.
Flexible: Four feed systems are available: air-feed, extended air-feed, pile feed and continuous with in-line FD 676 Maxi Burster.
Color Touchscreen Control Panel: Graphics-based and designed for easy, walk-up use.
Pre-Programmed Folds: 20 standard folds are pre-set for qucik and easy operation.
Programmable Jobs: Up to 200 jobs can be easily programmed and stored in memory.
Counters: Resettable and batch counters.
Fold Types: Z, uneven Z, C, Half and custom folds.
Conveyor with Photo Eye: Adjustable 28"-42" conveyor for neat, sequential stacking.
Interlocks: For fault detection and operator safety.
Combination Rollers: Steel & polyurethane rollers for durability.
Insulated Fold Plates: Rugged fold plates are insulated for quieter operation.
Options:
Center Slitter & Two-Up Form Kit.
V-STACK36 Vertical Stacker: Aligns with the outfeed and vertically stacks up to 22" of folded documents, making them easier to unload for further processing.
Item Specifications
Hopper Capacity:
FD 2300 (AutoSeal High-Volume Production
Pressure Sealer - Air Feed Table): Up to 500 Sheets 24# (90gsm)
FD 2300-EX (AutoSeal High-Volume Production
Pressure Sealer - Extended Air Feed Table): Up to 1,000 Sheets 24# (90gsm)
FD 2350 (AutoSeal High-Volume Production
Pressure Sealer - Pile Feeder): Up to 3,500 Sheets 24# (90gsm)
FD 2380 (AutoSeal High-Volume Production
Pressure Sealer - Continuous
Form with FD 676 Burster): Continuous Forms
Variable Speed: Up to 43,000 sheets per hour – based on 11" Z-Fold (279mm)
Paper Size:
FD 2300/2350/2380: Up to 11.5" W x 25" L (292 W x 635 L mm)
FD 2300-EX: Up to 11.5" W x 14" L (292 W x 356 L mm)
Usage: Production
Power: 208V, three phase, 20 Amp(Special 3 Phase Power Required) NEMA L14-20P plug included, NEMA L14-20R receptacle required
Dimensions:
Cut-sheet models: 152" L x 30" W x 56" H (386 L x 76 W x 142 H cm
FD 2380: 167" L x 30" W x 56" H (425 L x 76 W x 142 H cm)
Weight: Approx. 1,200 lbs (544 kg)
Delivery Requirements: Customer-supplied fork lift is required for installation and setup
Certifications: UL applied for
Demonstration Video
Formax AutoSeal 2300 Series Pressure Sealers Demo Video
Transcript :
Formax 2300 series production pressure sealers. Formax 2300 series production pressure sealers are designed to handle high volume jobs with ease and dependability. Fully automated settings for quick and easy setup, and speeds of up to 43,000 forms per hour, set the industry standard for speed and production capabilities.
The 2300 series offers three in-feed options: the FT 2300 utilizes an air feed system with a loading capacity of up to 500 forms, the FD2300 EXT utilizes an extended air feed system that offers a capacity of up to 2500 forms, and the FD2350 utilizes a pile feed system with a ...
Formax 2300 series production pressure sealers. Formax 2300 series production pressure sealers are designed to handle high volume jobs with ease and dependability. Fully automated settings for quick and easy setup, and speeds of up to 43,000 forms per hour, set the industry standard for speed and production capabilities.
The 2300 series offers three in-feed options: the FT 2300 utilizes an air feed system with a loading capacity of up to 500 forms, the FD2300 EXT utilizes an extended air feed system that offers a capacity of up to 2500 forms, and the FD2350 utilizes a pile feed system with a total capacity of up to 3,500 loaded forms. Each model has a centrally located color touch screen which allows users to set fold type, form length, and speed.
State-of-the-art automated features make job changes quick and accurate, and up to 200 custom jobs can be programmed and stored into memory. Heavy-duty fold plates are designed to handle a variety of fold types, while the rugged combination of steel and polyurethane fold rollers provide durability in a production environment. Four-fold plates are used to offer flexibility in both folding and the output sequence of processed forms.
To operate the 2300 series, begin by switching on the main power. Next, load forms onto the feeder, then use the control panel to easily select your job settings. Press the feeder activation button followed by the green and red folder start button, then the feeder start button to begin feeding forms. Finally, adjust the desired processing speed.
Watch how the feeder slowly rises as the forms are being fed. As the forms exit the seal rollers, notice how they're stacked in a neat sequential order on the adjustable output conveyor. The conveyor has its own set of controls which make it easy to unload the processed mail-ready pieces.
These features make the 2300 series the ideal solution for Fortune 500 companies and mail houses requiring heavy-duty industrial equipment for fast and reliable performance. The Formax 2300 series clearly sets the standard for high volume pressure seal processing
90 day limited warranty on parts. Excluding wearables and labor.
AutoSeal FD 2300 Series
FD 2300 (AutoSeal High-Volume Production Pressure Sealer - Air Feed Table): Up to 500 Sheets 24# (90gsm) FD 2300-EX (AutoSeal High-Volume Production Pressure Sealer - Extended Air Feed Table): Up to 1,000 Sheets 24# (90gsm) FD 2350 (AutoSeal High-Volume Production Pressure Sealer - Pile Feeder): Up to 3,500 Sheets 24# (90gsm) FD 2380 (AutoSeal High-Volume Production Pressure Sealer - Continuous Form with FD 676 Burster): Continuous Forms
Up to 43,000 sheets per hour – based on 11" Z-Fold (279mm)
FD 2300/2350/2380: Up to 11.5" W x 25" L FD 2300-EX: Up to 11.5" W x 14" L
208V, three phase, 20 Amp(Special 3 Phase Power Required) NEMA L14-20P plug included, NEMA L14-20R receptacle required
Cut-sheet models: 152" L x 30" W x 56" H FD 2380: 167" L x 30" W x 56" H
Approx. 1,200 lbs
UL applied for
90 day limited warranty on parts. Excluding wearables and labor.
