Formax FD 262 Single-Head Crash Tabber
7095 NewCondition InStock

Formax FD 262 Single-Head Crash Tabber

Part #: FD 262
Brand: Formax
  • Speed: Up to 12,000 pieces per hour (8.5" tri-folds)
  • Feeder Capacity: Up to 200 tri-folds and Integrated bottom feeder for continuous operation
  • Media Thickness: Up to 5/32"
  • Duty Cycle: Up to 30 million addresses or 500,000 per month over a 5-year cycle
  • 90 Day Warranty
  • Price Match Guarantee
  • Oversize / Truck shipping
  • Brand New
In Stock

$7,095.00

This Item Ships Via Truck
SWIPE FOR MORE IMAGES
  • 0
  • 1
  • 2
  • 3
  • 4
  • 5
video

Product Description

This Formax FD 262 Single-Head Crash Tabber automatically apply adhesive tabs or wafer seals and offer a cost-effective alternative to envelopes when mailing brochures, newsletters and other folded mailers. This Formax FD 262 Tabber processes up to 12,000 tri-folds per hour, in sizes up to 17" wide and up to 5/32" thick. It has the flexibility to use a variety of translucent, paper and clear tab stocks. Standard features include an integrated bottom feeder which allows for continuous operation, a built-in waste take-up spool, 5-digit LCD counter, and tab sensitivity adjustment. This tabbing system has an all-steel construction that makes it rugged and very durable. This Formax FD 262 Single-Head Crash Tabber is 100% made in the USA, providing dependable and flexible solutions to keep your mailings in compliance with changing USPS tabbing regulations.

Product Details

  • Tabs up to 12,000 pieces per hour.
  • Handles media up to 17" wide.
  • Designed to handle a variety of tab stock including translucent and paper.
  • 5-digit resettable counter.
  • Integrated bottom feed for continuous operation.

Item Specifications

  • Speed: Up to 12,000 pieces per hour (8.5" tri-folds)
  • Feeder Capacity: Up to 200 tri-folds
    Integrated bottom feeder for continuous operation
  • Media Size: 3" to 18" L
    5" to 17" W
  • Media Thickness: Up to 5/32"
  • Tab Size: 5/8" to 1 1/2"
  • Tab Materials: Translucent, Paper, Clear
  • Tab Sensitivity Control: Adjusts for density in tab/wafer seals
  • Tabs Applied: 1 tab per pass
  • Tab Roll Capacity: Up to 10,000 tabs
  • Tab Roll Size: Maximum roll diameter: 9"
  • Core diameter: 3"
  • Counter: 5-digit LCD, resettable
  • Duty Cycle: Up to 30 million addresses or 500,000 per month over a 5-year cycle
  • Dimensions: 25" W x 22" H x 15.5" D
  • Weight: 40 lbs
  • Power: 120VAC, 50/60Hz
  • Options: Drop-Stacking Conveyor Stacker
  • Made in USA
  • Warranty: 90 day limited warranty on parts, excluding wearables and labor

Product Reviews

Write Your Own Review
You're reviewing:Formax FD 262 Single-Head Crash Tabber
Your Rating

Demonstration Video

Formax FD 262 Single-Head Tabber Demo

Transcript: Formax FD 262 Tabbing System. The Formax FD 262 single head tabbing system makes quick work of applying tabs to folded mail pieces. Using crash tab technology, the FD 2062 applies, folds, and seals an adhesive tab to the open edge of a mail piece making it compliant with USPS mailing regulations. The FD 262 includes an integrated bottom feed system ideal for continuous operation and a catch tray to neatly stack finished pieces. An optional conveyor is also available for increased output capacity, operators will find the controls intuitive and easy to use including a resettable five-digit LCD c ... Read More
Formax FD 262 Tabbing System. The Formax FD 262 single head tabbing system makes quick work of applying tabs to folded mail pieces. Using crash tab technology, the FD 2062 applies, folds, and seals an adhesive tab to the open edge of a mail piece making it compliant with USPS mailing regulations. The FD 262 includes an integrated bottom feed system ideal for continuous operation and a catch tray to neatly stack finished pieces. An optional conveyor is also available for increased output capacity, operators will find the controls intuitive and easy to use including a resettable five-digit LCD counter and tab sensitivity adjustment knob. Various tab stocks can be used including translucent and paper in sizes up to one and a half inch in diameter. The FD 262 holds rolls up to 9 inches in diameter and includes a built-in waist take-up spool which helps reduce downtime. To meet USPS requirements for mailing and automation discounts, a mail piece can be fed through the FD 262 multiple times in different directions. To apply tabs in a variety of locations the FD 262 tabs up to 12,000 pieces per hour and can accommodate media up to 17 inches wide. With ever-changing postal regulations having the dependable FD 262 tabbing system can make your mailings compliant with very little effort.
