Shreds old and obsolete cardboard to robust packaging material.
Well designed controls: lockable power switch is also an emergency stop switch.
Single pass operation.
Lockable master switch.
ProductDescription
Using the Intimus PacMaster you can easily turn your old boxes into packing material. The Pacmaster offers a high volume solution is economical and reliable: the special PacMaster technique converts empty corrugated boxes, which previously cost money to dispose of, into "free" large-volume filler material suitable for packing even sensitive goods for transport. Best of all - it's EASY TO USE! The corrugated boxes are simply cut to the required format in the preliminary cutter. The working surface has standard size guides marked on it and along with the sliding guide, accurate cutting is guaranteed. The strips are then fed into the inlet where specially patented cutting shafts turn them into bulky packing mats.
Product Details
Shreds old and obsolete cardboard to robust packaging material.
Well designed controls: lockable power switch is also an emergency stop switch.
Single pass operation.
Lockable master switch.
Size guide on the work surface to ensure accurate cutting of the cardboard to customise the stuffing mats to required format.
Extremely robust steel plate housing for heavy duty use at the packing station.
Item Specifications
Pad grid: 4 x 110 mm
Shredding capacity: 5 - 7 m³/ pre-processed material
Carton: 2 - 3 layers
Cutter Feed width / height: 425 / 15 mm
Cutting Speed: 7.1in/sec / 18cm/sec
Supply Voltage: 400 V
Noise level (dB(A)): 62-68.5
Width: 27.1" / 69cm
Depth: 18.5" / 47cm
Height: 37.4" / 95cm
Weight308.6 : 308.6 lbs / 140 kg
Demonstration Video
Imtimus PacMaster by Martin Yale Demo Video
Transcript :
The Imtimus PacMaster by Martin Yale. Turn your excess boxes into free packaging material. In one pass you can trim and perforate. Easily handles 4-plies of corrugated cardboard. Perforates at a speed of 35 feet per minute. Ruler to cut the corrugated to the exact size needed. Rotary knobs control on, off and reverse functions. Safety features include lockable main switch with removable safety lock key. The PacMaster is on locking casters for complete mobility when needed. Optional vacuum kit is available. Great for use in manufacturing and industrial packing environments. Turn negatives into ...
The Imtimus PacMaster by Martin Yale. Turn your excess boxes into free packaging material. In one pass you can trim and perforate. Easily handles 4-plies of corrugated cardboard. Perforates at a speed of 35 feet per minute. Ruler to cut the corrugated to the exact size needed. Rotary knobs control on, off and reverse functions. Safety features include lockable main switch with removable safety lock key. The PacMaster is on locking casters for complete mobility when needed. Optional vacuum kit is available. Great for use in manufacturing and industrial packing environments. Turn negatives into positives by taking excess boxes and making needed packing material. This saves money and the environment. Go grenn with the Intimus PacMaster by Martin Yale.
Intimus PacMaster S 220v Cardboard Shredder Review
Ever wish you could do something productive with all those unused cardboard boxes going into the recycling? Well now you can. With the Intimus PacMaster, old cardboard boxes can be turned into new packing material. You'll save money on packing items and still stay green by reusing the boxes, making this machine both economical and environmentally friendly. Let's take a closer look at the PacMaster S Cardboard Shredder.
Strengths:
This device is very easy to use. A lockable main switch with a removable safety key turns on the main power supply and also acts as an emergency stop. An easily controlled rotary knob controls on, off, and reverse functions.
Have a box that is just a little too wide? A built in cutter trims off any piece wider than the opening. A ruler on the front offers exact measuring to slice the items into standard sizes or to the specifications of your choice. You can choose the exact size you need to cut to protect fragile items. A sheet of cardboard can be trimmed and perforated all together in one pass.
As with many Intimus shredders, the cutting cylinders are covered by a five year warranty. Parts and labor carry warranty coverage for one year. You can rest assured that you're getting a high quality machine.
A wide 16-3/4 inch opening accepts two pieces of 2-ply cardboard at one time through the ¾ inch high feed slot. The cutting shafts turn the corrugated pieces into grid cut packing material. Newspaper or non-confidential computer printouts as well as regular paper can also be shred into filler material for shipping. Boxes are shred at 35 feet per minute. Your recycling stack can quickly be turned into large amounts of volume filler material for transporting even the most fragile items.
An optional vacuuming kit offers a convenient way to clean up the mess created by this machine.
Weaknesses:
This shredder weighs about 309 pounds when empty. If it weren't for the casters mounted on the bottom, it would be bulky and awkward to move around a large warehouse. Fortunately, the casters offer added mobility. They also lock in place to keep the machine from rolling around during use. We think weight won't be much of an issue for most users.
A machine like this will create a fair amount of dust from all the shredded cardboard. While this isn't a huge problem, we suggest getting the optional vacuuming kit to aid in the cleanup that will be needed.
One last thing that would be nice on this machine is the option to make little pieces instead of only thick packing mats. However, depending on the number of sheets they can shred at once, this can be done with many regular shredders.
For the efficient and economical disposal of cardboard into useful material, the PacMaster is ideal. Able to quickly shred 2 pieces of cardboard at once into your preferred size, this shredder offers the convenience of taking materials you already have on hand and turning them into something you once paid for. We think the PacMaster is the perfect system for any manufacturing or industrial business.
Recommended for you
Navigating through the elements of the carousel is possible using the tab key. You can skip the carousel or go straight to carousel navigation using the skip links.
Press to skip carousel
It is best to remove staples before shredding as the brass staples can chip the cutting head and can actually void the warranty. If you need help placing an order for this machine, please give us a call at 800-944-4573.
When shredding/perforating cardboard this unit will produce a fairly large amount of paper dust. In most warehouse environments this isn't a huge deal. However, some users will add the Vacuum kit onto the unit in order to cut down on airborne dust and to keep their work area clean and tidy.
The current cost for the optional Vacuum kit is $414. However, if you would like to add this onto your cardboard shredder you will need to call at the time of your order so that we can verify current cost and make sure that it gets included.
