Logan 4000 Deluxe Pull-Style Bevel Handheld Mat Cutter

The 4000 Deluxe Pull Style Bevel Cutter features a start-and-stop indicator, a marker bar with pencil lead, and a rotating blade holder. To install a blade, first loosen the retaining screw on the back of the cutting head and rotate the blade holder all the way up. Then loosen the blade knob. Install one Logan 270 blade sharp side down into the back of the blade holder and retighten the blade knob. Rotate the blade holder down and retighten the retaining screw. To adjust the blade depth on the 4000 Deluxe Pull Style Bevel Cutter, find the blade depth adjustment screw on the bottom of the cutting head. Using a screwdriver, turn the screw clockwise to decrease the blade depth or counterclockwise to increase the blade depth. See that the blade depth is set so the blade barely passes through the mat board and only scores into your slipsheet. To bevel cut an opening using the 4000, first always use a slipsheet. You may find it easier to tape the slipsheet in place. To mark a border using the 4000 Deluxe Pull Style Cutting Head, adjust the marker bar so the scale-setting on the marker bar aligns with the edge of the mat cutting head, in this example, a 2-inch border. And retighten the marker bar in place. Using the pencil lead on the marker bar and pressure with your thumb, draw the cutting head along the outside edges of the mat board to draw the four borders. Using a suitable straight edge, align the straight edge along the pencil lines and rest the bevel cutting head against the straight edge. Align the start and stop indicator, rotate the blade end, and pull back to the near line. Always make sure to retract the blade after each cut. After the fourth cut, you will have a perfectly beveled mat.

To adjust the blade depth on a push style double cutting head, find the blade depth adjustment screw on the underside of the cutting head. And using a screwdriver, turn the screw clockwise to decrease the blade depth or counterclockwise to increase the blade depth. See that the blade is barely passing through the mat board and only scoring into the slip sheet. To adjust the blade depth on the 302 bevel cutter, find the blade depth adjustment screw on the bottom of the cutting head. Using a screwdriver, turn the screw clockwise to decrease the blade depth or counterclockwise to increase the blade depth. See that the blade is just barely passing through the mat board and only scoring into the slip sheet. To adjust the blade depth on the straight cutter of the 650-1 Framer’s Edge Elite, loosen the blade holding knob and use the blade depth adjustment knob to increase or decrease the blade depth. Then retighten the blade knob. To adjust the blade depth on the bevel side of the 650-1 Framer’s Edge Elite, first loosen the blade holding knob and using the blade depth screw. Turn the screw in or out to increase or decrease the blade depth. Then retighten the blade knob. To adjust the blade depth on the 50008 ply mat cutter, loosen the blade knob and remove the blade holding magazine. Using the neural blade depth adjustment screw, turn the screw clockwise or counterclockwise to increase or decrease the blade depth. Then reinstall the blade holding magazine and retighten the blade holding knob. See that the blade depth is just barely passing through the thickness of the mat board and only scoring into the slip sheet.
