The HSM ProfiPack 425 Dust Extraction Hose and Fittings will rip through multiple layers of tough cardboard. Go green with this portable and powerful tool. Ideal for large archives or as a central shredding point.
Product Details
30 Micron Upper & Lower Bag Filtration.
9" Balanced Steel, Radial Fin Impeller.
Steel Base with Casters for Mobility.
Green Powder Coated Paint.
Specifications
Product Dimensions:
Weight: 57 lbs.
Width (side-to-side) x Depth (front-to-back) x Height: 25-1/2 x 15 x 63 in.
Footprint (Length x Width): 25-1/2 x 15 in.
Shipping Dimensions:
Type: Cardboard Box
Content: Machine
Weight: 67 lbs.
Length x Width x Height: 19 x 27 x 17 in.
Must Ship Upright: No
Electrical:
Power Requirement: 110V, Single-Phase, 60 Hz
Prewired Voltage: 110V
Full-Load Current Rating: 8A
Minimum Circuit Size: 15A
Connection Type: Cord & Plug
Power Cord Included: Yes
Power Cord Length: 10 ft.
Power Cord Gauge: 16 AWG
Plug Included: Yes
Included Plug Type: 5-15
Switch Typ: Paddle Safety Switch w/Removable Key
Motors:
Type: TEFC Capacitor-Start Induction
Horsepower: 1 HP
Phase: Single-Phase
Amps: 8A
Speed: 3450 RPM
Power Transfer: Direct Drive
Bearings: Sealed & Permanently Lubricated
Operation:
Dust Collector Type: Single-Stage
Approved Dust Types: Wood
Filter Type: Bag
Airflow Performance: 500 CFM
Max Static Pressure (at 0 CFM): 2.76 in.
Main Inlet Size: 4 in.
Inlet Adapter Included: No
Machine Collection Capacity At One Time: 1
Maximum Material Collection Capacity: 2.3 cu. ft.
Filtration Rating: 30 Micron
Bag Information:
Number of Upper Bags: 1
Number of Lower Bags: 1
Upper Bag Diameter: 14-1/2 in.
Upper Bag Length: 24 in.
Lower Bag Diameter: 14-1/2 in.
Lower Bag Length: 23 in.
Impeller Information:
Impeller Type: Radial Fin
Impeller Size: 9 in.
Impeller Blade Thickness: 3/32 in.
Construction:
Upper Bag: Fabric
Lower Bag: Fabric
Base: Steel Sheet Metal w/Casters
Frame: Formed Steel
Caster: High Density Plastic
Impeller: Steel
Paint Type/Finish: Powder Coated
Country of Origin: China
Warranty: 1 Year
Approximate Assembly & Setup Time: 45 Minutes
Serial Number Location: ID Label
Sound Rating: 83 dB
ISO 9001 Factory: Yes
Certified by a Nationally Recognized Testing Laboratory (NRTL): No
Awards: Popular Woodworking Best New Tool 1999, Popular Woodworking Editor's Choice
