Product Description
This Mactac Rebel X-Treme RB528X Matte White High-Tack 54" x 50' Vinyl Print Media is a 4 mil matte opaque white, PVC film designed for the production of extremely permanent graphic applications. The product is coated on one side with 3 mils of an extremely aggressive permanent, specially blended, clear pressure sensitive adhesive which bonds to most smooth and moderately rough surfaces. The adhesive is protected with a 90# polycoated 2-side SuperFlat liner. The film face is 99% opaque and designed for excellent printability with solvent, eco-solvent, latex and UV-cured inkjet printers and is also printable with UV or solvent screen inks, UV offset and UV flexographic inks and is thermal transfer printable.
Product Details
- Features and Benefits:
- REBEL X can be printed on multiple platforms: Screen, latex, UV and solvent ink jet, thermal transfer, UV Flexo and UV offset.
- Five year or better outdoor durability.
- Brilliant blue white face offers the best base for great color reproduction, especially with high intensity images.
- Typical Uses:
- Any job where your graphic just has to stick and stay stuck!
- Indoor and outdoor concrete surfaces: support pillars and smooth to slightly rough concrete or cinder block walls.
- Tough-to-adhere to applications like trash cans, storage bins, moderately pebbled surfaces.
| Property | Typical Values | Test Method |
| Quick Tack lb. /in² (N/25mm) Stainless Steel |
6.5 (33) |
PSTC-3 |
| Peel Adhesion lb./in. (N/25 mm) Stainless Steel -30 min. - 24 hr. |
7.0 (30) 10 (43.5) |
PSTC-1 (CTM-25) |
| Dimensional Stability, inches (mm) 48 hours @ 158°F |
Max. 0.05 |
MACtac CTM-21 10" x 10" Sample Bonded to aluminum |
| Shear, Hours to failure Stainless steel - 5# weight @ 72°F |
300+ |
PSTC-7 |
| Temperature Range Minimum Application: End Use: |
40°F (4.4°C) | - 30°F to 225°F (35°C to 107°C) |
| Surface Burning Characteristics (Meets ANSI, NFPA,& IFC as class A) Flame Spread Smoke Density |
10 25 |
ASTM E84-01 or ANSI/NFPA 255 or IFC 8-1 |
| Opacity | 96 - 99 | X-Rite Densitometer |
- Whiteness and Brightness
- Brightness 88.5
- ASTM Whiteness 110.24
- CIE Whiteness 106.7
- CIE Tint 2.26
The outdoor durability of the unprinted film is 5 - 7 years on vertical surfaces.
2 year from D.O.M. when stored at 60/77°F (15/25°C) and 50% relative humidity in the originalpackage.
REBEL X is intended to be a Permanent application.
Screen Printing: HP Indigo No
UV Cured Yes Off-set No
Solvent Yes UV Off-set Yes
WF Digital: UV Inkjet Yes Thermal Transfer Yes
Eco-solvent Yes Flexographic* No
True solvent Yes UV Flexographic Yes
Latex Yes Narrow Web UV Inkjet Yes
* Flexographic Printing requires a topcoat. WVG000113 has been approved by ACTEGA Coatings and Sealants (ww.altana.com) as in-line coat-able ink primers. To achieve the best possible print quality, please make sure that the correct ICC profiles or printer settings are used. Profiles can be obtained from our Distributors or can be downloaded from www.mactac.com . Printer and heater settings and ICC profiles can also be downloaded from some O.E.M. or software manufacturer’s websites.
The ICC profiles are provided solely as a customer resource. Print environments, the individual nature of printing systems, inks and software can significantly affect output. It is the customer’s responsibility to determine the suitability of any profile for use in their specific print environment.
- 1) REBEL X will result in a permanent application and will not be easily removed from most surfaces. Always test first in an inconspicuous area.
- 2) REBEL X on varnished surfaces and soft walls like stucco or drywall may damage the surface upon removal. Always test first in an inconspicuous area.
- 3) REBEL X is not intended to be used as a conformable wall wrapping film.
- 4) REBEL X is not intended as a vehicle wrap film.
1) The user is responsible for determining the product’s suitability, including adhesion and if needed, removal characteristics when used in applications other than listed specifically in this Performance Guide.
2) If there are any questions about applications, please contact your Mactac sales representative to discuss your requirements for recommendations.
3) If this is a printed Performance Guide it is an uncontrolled document. Please check the Mactac website for the latest, most up-to-date version.
Always test your combination of REBEL products, inks and laminating films prior to commercial use.
- 1) Printing Conditions: Print in conditioned pressroom at ±73°F (23°C) and 50% RH. The maximum allowable ink saturation is 270%.
- 2) Drying Requirements: Solvent, Eco-solvent and Mild-solvent inkjet prints require 24 - 48 hr. drying time - open to the air. Inks do not dry when printed media is rolled up. The prints must be dry prior to lamination.
- 3) Laminating: lamination of the inkjet-printed graphics with PERMACOLOR will help maintain and in some cases extend, the life of your graphic.
- 4) Transportation Conditions: To allow for easy transportation, REBEL X can be rolled up, with the image out, with a minimum diameter of 6 inches (15cm). During transportation or storage, avoid exposing them to extreme temperature and humidity changes.
- 5) Application Requirements: The surface must be dry, clean and in reasonably good condition.
- a) REBEL X must be applied in dry conditions at temperatures above 40°F (10°C). Heat helps the adhesive flow to the surface to create a faster bond.
- b) Please refer to TA2032 for proper surface preparation.
- c) Bridge graphics over seams if needed; do not force the graphic down into the seam.
- d) Use the ‘hinge’ application method. Since this is an aggressive adhesive, make sure you have your alignment right the first time. Measure twice, apply once.
- e) The rougher the surface the less contact the adhesive will have and the less chance your graphic has for success. So on moderately rough surfaces use heat and pressure to conform the graphic into the surface. Once complete go back over all the entire graphic to get as much adhesive contact as possible with the surface.
- f) If possible trim sharp corners to a rounded radius to help minimize the potential of edge lifting.
- g) If needed, use a 1" overlap to seam the graphic.
- Values given are typical for unprocessed product and are not for use as specifications. Processing may change the values.
- Product reinforced with 2-mil polyester during adhesion tests.
Specifications
- Adhesive Category: Extra Permanent
- Adhesive Type: Permanent Acrylic
- Color: White
- Films: Vinyl (PVC)
- Finish: Matte
- Length: 50'
- Width: 54"
- Liner Category: 90# Superflat
- Outdoor Durability: 5 Years
- Precise Program: N
- Print Method: Eco-Solvent Inkjet, Inkjet, Latex, Narrow Web UV Inkjet, Offset, Solvent Screen, Thermal Transfer, UV Cured Screen, UV Inkjet, UV Offset
- Thickness: 4.0 mil
