Product Description
The ProSeal 25" Pouch Board Laminator is the latest and greatest in fast, easy-to-use, and cost-effective finishing systems. Its simple, one-step operation, on-demand capabilities, minimal maintenance, mounting and laminating your graphics materials is quick, easy, and convenient. And you'll always be assured of consistent, high-quality results, thanks to the machine's industry-leading design, smooth performance, and a host of capabilities that will help you streamline the graphics production of a wide range of printed media.
Product Details
- Height: 12" (305 mm)
- Overall Width: 40" (1016 mm)
- Depth: 15" (380 mm)
- Net Weight: 77 lbs. (35 kg)
- Shipping Weight: 90 lbs. (41 kg)
- Maximum Working Width: 25" (635 mm)
- Process Speed: 1 ft/min (305 mm/min)
- Roller Line Pressure: 1 N/mm
- Process Temperature: 311-320°F (155-160°C)
- Nip Settings: 0 (closed nip)
1/16" (1.5mm)
1/8" (3mm)
3/16" (5mm)
1/4" (6mm)
- Electrical: 110 VAC / 60 Hz / 12A
Staff Review
ProSeal 25-Inch Pouch Board Laminator Review
Pouch board laminators are very versatile machines that provide functionality and quality results. The ProSeal 25 Inch Pouch Board Laminator offers lamination and mounting, as well as both together for a handy machine for any business. The compact design allows this machine to fit well in any office, no matter the size. Here is a closer look at the details.
Strengths:
- The space saving design of this laminator allows it to be used on a large desk or table. This is especially nice if you like to sit while processing large batches.
- It uses silicone rollers for smooth results every time. The silicone will provide crystal clear results without sticking to your documents. This, along with easy clean features, provide a simple machine that needs minimal maintenance.
- A thickness selector knob gives the user manual control of the nip opening. It has options for 0 (closed), 1/16″, 1/8″, 3/16″, and ¼” openings. Mounting boards can go through at any of those sizes as well as window signs, documents, trade show graphics, and anything else within this size range.
- If your item begins to enter crooked or get jammed, simply switch the device into reverse. Your material will be fed back out to you for re-entry.
- The heat is digitally controlled by preset variables to guarantee consistent temperature. This device operates at a maximum temperature of 320 degrees Fahrenheit. As a result, you can just insert items and let the laminator do the work for you without having to guess which is the best temperature.
- The design also features preset roller pressure. Your items will receive the compression needed for wrinkle free laminating.
- Versatility is seen in the laminating abilities of the ProSeal. It provides three options. Items can be laminated as normal. Or you can use this device for mounting. For ultimate efficiency, it also offers laminating and mounting in one easy step.
- Materials come through at a rate of one foot per minute. Films can be as wide as 25 inches. This allows the protection of smaller posters, meeting signs, graphics and more.
- ProSeal provides a one year warranty on this pouch board laminator.
Weaknesses:
- This machine doesn’t offer cold lamination. This means you can’t laminate heat sensitive items, such as photos and inkjet prints. It also means you can’t use pressure-sensitive films. If you don’t foresee yourself needing to use materials that may be damaged by heat, then this device will work well for you. Otherwise we recommend the Phoenix 44″, which offers both hot and cold lamination and conveniently comes with roll film.
- This device weighs about 70 pounds, which isn’t overly heavy but could be awkward to move. If you need a shared machine that can relocate easily, we suggest storing this device on a cart for added mobility.
Although this is a smaller device, the ProSeal 25 Inch Pouch Board Laminator works well for what it was designed to do. Offices using pre-coated thermal activated mounting boards as well as pouch boards will find this device excellent for their needs. You’ll be able to create meeting signs, court exhibits, point of purchase displays, whatever you need within the size limitations. So be sure to check out the ProSeal 25 Inch Laminator today so you can get started.
