Product Description
A simple, fast and efficient solution for your Laminating, Mounting and Pre-Masking needs. This Royal Sovereign 158" Multi-Applicator Illuminated and Fixed Height Table for Mounting and Lamination is the next evolution of flatbed application tables. Utilizing the compact and practical module technology, this multi-applicator is simple to install. Enhanced Features include: Precise, Laser Cut Aluminum Profiles, Best In Class Full Length LED Illumination and Pneumatic Roller Pressure with Independent Activation Toggles.
Product Details
- True Table Size - Maximize your production potential. With a maximum working and application width of 63", maximum working length of 4 meters (158") and maximum application length of 146" the Bobis Multi-Applicator offers the truest dimensions and most practical utilization of working space.
- Best In Class Table Illumination - Utilizing laser cut acrylic diffusion panels and LED strips set inside the frame to provide a dust free, clear and even light distribution, with no unsightly grid-lines.
- Laser Cut Aluminum Profiles - Precise European craftsmanship. Each piece of the module has been meticulously engineered and produced to provide smooth edges and barely there seams. The accuracy with which these pieces were crafted will allow for simple installation, long lasting use and easy expansion.
- Maintenance Free Roller Transport - High density bearings effortlessly glide along aluminum rails producing a smooth and friction free transport. Unlike transports with steel bearing riding along a steel profile, daily cleaning and greasing is not required.
- Ergonomic Fixed Table Height - Designed with your comfort in mind, the application rests at a height to provide maximum productivity and convenience.
Specifications
- Model Number: BMA-160/400LV
- Table Height: Fixed 32 in. (810 mm)
- Bed Width: 68" (1725 mm)
- Bed Length: 161" (4090 mm)
- Working Width: 63" (1600 mm)
- Working Length: 158" (4000 mm)
- Application Width: 63" (1600 mm)
- Application Length: 148" (3710 mm)
- Max Substrate Thickness :2.5 in. (65 mm)
- Roller Diameter: 5.7 in. (145mm)
- Application Table Surface: Self-Healing
- Illumination: Full Length LED Illumination
- Required Air Pressure: 60-90 PSI
- Options: Attachable 63" Film and Roll Holder
- Customized Sizes: Contact Us For Pricing
- Warranty: 36 Months (Parts and Labor)
