We're sorry, but we no longer offer this item.

Call us at 1-800-944-4573 for personalized recommendations
check out these similar items that may be a good fit

Visual Magnetics InvisiLock-30HP Sheet Magnet - 23.875" x 23.875" White 1-Sided Adhesive Backed High Energy (15pk)

We're here for you!

Please call
1-800-944-4573
for help finding a comparable solution

Need Shopping Advice?
Call - (800)944-4573

Item#

Size: 23.875" x 23.875"
otal Caliper: 30-mil / 762 Micron
Opacity: 100%
Gauss @ 0.25" gap : <1

Product Description

This Visual Magnetics InvisiLock-30HP Sheet Magnet is a 23.875" x 23.875" adhesive-backed high-energy white magnet with surface protect that is designed specifically for use with the Visual Magnetics Graphic System. The InvisiLock-30HP can be applied to smooth interior fixture surfaces. The high-energy magnetic surface supports up to 4 MagnaMedia layers allowing for special promotions or accents to be applied on top of a base graphic. The InvisiLock-30HP includes Surface Protect, a white, scuff-protective layer, which safeguards graphics from marring when applying multiple layers. Get 15pk on every order of Visual Magnetics InvisiLock-30HP 23.875" x 23.875" Sheet Magnet.

Product Details

Surface Protect: white, scuff-protective layer.
Supports up to 4 MagnaMedia layers.
Proprietary polarity allows InvisiLock fixtures to lock in place.
Flexible sheets for application to concave and convex surfaces.
Excellent lay flat.
Easy to cut and trim with a utility knife or scissors.
Magnet engineered to low gauss level for safety.
Adhesive-backed magnet does not require ActiveWall® primer.
Use with any MagnaMedia product.
Best for indoor fixture applications.
Do not roll this material to less than 4" diameter, as adhesive wrinkling may result.

Specifications

Size: 23.875" x 23.875"
Total Caliper: 30-mil / 762 Micron
Opacity: 100%
Gauss @ 0.25" gap : <1
Pull Force: 91# / SF
Adhesive Peel Adhesion: 8# / in
Adhesive Tensile Strength (MD/CD): 10# / in
Adhesive Elongation (MD/CD): 100 / 90%

Technical Data

Visual Magnetics InvisiLock custom engineered magnet is designed specifically for use with the Visual Magnetics Graphic System. VM-InvisiLock-30HP can be applied to smooth interior fixture surfaces. The high-energy magnetic surface supports up to 4 MagnaMedia layers allowing for special promotions or accents to be applied on top of a base graphic. VM-InvisiLock-30HP includes Surface Protect, a white, scuff-protective layer, which safeguards graphics from marring when applying multiple layers.

Features and Benefits

Surface Protect: white, scuff-protective layer.
Supports up to 4 MagnaMedia layers.
Proprietary polarity allows InvisiLock fixtures to lock in place.
Flexible sheets for application to concave and convex surfaces.
Excellent lay flat.
Easy to cut and trim with a utility knife or scissors.
Magnet engineered to low gauss level for safety.

Application Information

Adhesive-backed magnet does not require ActiveWall primer.
Use with any MagnaMedia product.
Best for indoor fixture applications.
Do not roll this material to less than 4" diameter, as adhesive wrinkling may result.

Physical Data

Total Caliper	30-mil / 762 Micron
Opacity	100%
Gauss @ 0.25" gap	<1
Adhesive Peel Adhesion	8# / in ; Stainless Steel – 30 min.
Adhesive Tensile Strength (MD/CD)	10# / in
Adhesive Elongation (MD/CD)	100 / 90%

Chemical Resistance

Resistant to water, detergent and alcohol. Not recommended for use in contact with aliphatic or aromatic hydrocarbons.

Shelf Life

One year when stored at 75° F (24°C) and 50% relative humidity or less.

Products / Sizes

PRODUCT CODE	AVAILABLE SIZES
VM30HP-24024	23.875 in x 23.875 in 15 tiles /case (60.6 cm x 60.6 cm)

Recyclability

VM-InvisiLock-30HP can be recycled using Visual Magnetics "Recycling Retired Graphics" program available for download at www.visualmagnetics.com.

Product Safety

InvisiLock magnet is a ferrite-based magnet and poses no health or safety issues. Unlike stronger, rare-earth neodymium permanent magnets, the multi-pole nature and lesser strength of ferrite magnets does not emit a strong magnetic field into the environment and therefore does not cause signal interference or damage with computerized equipment. At a gap of 0.25" or greater gauss readings are well below 1.0 and at 7 ft. the gauss level is "not recordable" using a Model 2010A Gauss Meter. Due to its low gauss emission, InvisiLock magnet is not recognized as a "magnetized material" per IATA (International Air Transportation Association) definition and therefore can be air shipped in bulk quantity.

Downloadable Information

Technical Data Sheet
Drytac Product Catalog 2017

Printer Compatibility Chart

FILMS	KEY FEATURES	BASE	NOMINAL THICKNESS	SURFACE FINISH	SCREEN	LITHO / OFFSET	FLEXO	LATEX	SOLVENT (ECO)	UV- CURED	DIGITAL / OFFSET	WATER BASED INK JET
VM-POLYsatin	Excellent solvent printer performance	Polypropylene	11-mil	Satin	⚫	⚫	⚫	⚫	⚫	⚫	⚫	X
VM-POLYmatte	Universal compatibility	Polypropylene	12-mil	Matte	⚫	⚫	⚫	⚫	⚫	◐	⚫	⚫
VM-POLYeigh	Offers excellent heat resistance / temp fluctuation	Polyester	12-mil	Satin	⚫	⚫	⚫	△	X	◐	⚫	X
VM-POLYeight PLUS	Like POLYeight but thicker, whiter and wider	Polyester	13-mil	Satin	⚫	⚫	⚫	△	X	◐	⚫	X
VM-POLYfive	Optimum solution for layering graphics	Polyester	9-mil	Satin	⚫	⚫	⚫	◐	X	◐	⚫	X
VM-POLYeight UV	Offering excellent photo quality on UV printers	Polyester	12-mil	Gloss	⚫	⚫	⚫	◐	X	◐	⚫	X
VM-SYNpaper	Economical, bright white, durable print surface	Synthetic paper	12-mil	Satin	⚫	⚫	⚫	◐	X	◐	⚫	X
VM-POLYEDGE ULS	High Value, bright white, cross platform	Polyester	7.1-mil	Satin	⚫	⚫	⚫	⚫	⚫	⚫	⚫	X
VM-POLYEDGE UV	Highest Value, heavyweight, PVC free	Polypropylene	11-mil	Satin	⚫	⚫	⚫	X	X	⚫	⚫	X
FABRICS
VM-Canvas 22	Natural cotton fiber texture	100% cotton	22-mil	Soft-matte	⚫	⚫	⚫	△	⚫	⚫	⚫	X
VM-Harvest 32	Jute – burlap with latex fabric	Jute	32-mil	Matte	⚫	⚫	⚫	⚫	⚫	⚫	⚫	X
VM-Monarch 22	Recycled polyester fabric – plain weave	100% recycled PET	22-mil	Matte	⚫	⚫	⚫	⚫	⚫	⚫	⚫	X
VM-Luna 14	Recycled polyester fabric – poplin weave	100% recycled PET	14-mil	Matte	⚫	⚫	⚫	△	⚫	⚫	⚫	X
VENEERS
VM-Maple 12	Light maple woodgrain	FSC cellulose	12-mil	Semi-matte	⚫	⚫	⚫	◐	X	⚫	⚫	X
VM-Oak 12	Dark oak woodgrain	FSC cellulose	12-mil	Semi-matte	⚫	⚫	⚫	◐	X	⚫	⚫	X
VM-Walnut 12	Rich walnut woodgrain	FSC cellulose	12-mil	Semi-matte	⚫	⚫	⚫	◐	X	⚫	⚫	X
SPECIALTIES
VM-CHALKboard	Available in custom colors	Polyester	13-mil	Semi-matte	⚫	⚫	⚫	⚫	⚫	⚫	⚫	X
VM-CHALKboard PLUS	Printable and write with liquid chalk	Polystyrene	15-mil	Semi-matte	⚫	⚫	⚫	X	X	⚫	⚫	X
VM-DRYerase	Bright white non-ghosting	Polyester	13-mil	Gloss	X	X	X	X	X	⚫	X	X
PRINTABLE MAGNET
VM-PrintableMagnet-15SPM	White, printable, standard-energy magnet	Polypropylene / magnet laminate	15-mil	Satin	X	X	X	X	X	⚫	X	X

Compatibility Key: ⚫ VM certified best results ◐ Profile dependent X Not compatible △ HP Certified for Latex Inks
