We're sorry, but we no longer offer this item.
Call us at 1-800-944-4573 for personalized recommendations
check out these similar items that may be a good fit
Product Description
This Visual Magnetics InvisiLock-40HP Sheet Magnet is a 23.875" x 23.875" two-sided high-energy white magnet with surface protect that is designed specifically for use with the Visual Magnetics Graphic System. The InvisiLock-40HP attracts to surfaces that have been primed with ActiveWall, latex primer. The high-energy magnetic surface supports up to 4 MagnaMedia layers allowing for special promotions or accents to be applied on top of a base graphic. The InvisiLock-40HP includes Surface Protect, a white, scuff-protective layer, which safeguards graphics from marring when applying multiple layers.
Product Details
- Surface Protect: white, scuff-protective layer.
- High-energy magnet supports up to 4 MagnaMedia layers.
- Proprietary polarity allows InvisiLock fixtures to lock in place.
- Flexible sheets for application to concave and convex surfaces.
- Excellent lay flat.
- Easy to cut and trim with a utility knife or scissors.
- Magnet engineered to low gauss level for safety.
- Must use with ActiveWall ® Primer.
- Use with any MagnaMedia product.
- Best for wall applications.
Specifications
- Size: 23.875" x 23.875"
- Total Caliper: 40-mil / 1016 Micron
- Opacity: 100%
- Gauss @ 0.25" gap : <1
Technical Data
Visual Magnetics InvisiLock custom engineered magnet is designed specifically for use with the Visual Magnetics Graphic System. VM-InvisiLock-40HP attracts to surfaces that have been primed with ActiveWall, latex primer. The high-energy magnetic surface supports up to 4 MagnaMedia layers allowing for special promotions or accents to be applied on top of a base graphic. VM-InvisiLock-40HP includes Surface Protect, a white, scuff-protective layer, which safeguards graphics from marring when applying multiple layers.Features and Benefits
- Surface Protect: white, scuff-protective layer.
- High-energy magnet supports up to 4 MagnaMedia layers.
- Proprietary polarity allows InvisiLock fixtures to lock in place.
- Flexible sheets for application to concave and convex surfaces.
- Excellent lay flat.
- Easy to cut and trim with a utility knife or scissors.
- Magnet engineered to low gauss level for safety.
Application Information
- Must use with ActiveWall Primer.
- Use with any MagnaMedia product.
- Best for wall applications.
Physical Data
| Total Caliper | 40-mil / 1016 Micron |
|---|---|
| Opacity | 100% |
| Gauss @ 0.25" gap | <1 |
Chemical Resistance
Resistant to water, detergent and alcohol. Not recommended for use in contact with aliphatic or aromatic hydrocarbons.
Products / Sizes
| PRODUCT CODE | AVAILABLE SIZES |
|---|---|
| VM40HP-24024 | 23.875 in x 23.874 in 15 tiles/case (60.6 cm x 60.6 cm) |
Recyclability
VM-InvisiLock-40HP is fully recyclable / recoverable and can be reground and recovered to create new magnet material. See "Recycling Retired Graphics" program available for download at www.visualmagnetics.com.
Product Safety
InvisiLock magnet is a ferrite-based magnet and poses no health or safety issues. Unlike stronger, rare-earth neodymium permanent magnets, the multi-pole nature and lesser strength of ferrite magnets does not emit a strong magnetic field into the environment and therefore does not cause signal interference or damage with computerized equipment. At a gap of 0.25" or greater gauss readings are well below 1.0 and at 7 ft. the gauss level is "not recordable" using a Model 2010A Gauss Meter. Due to its low gauss emission, InvisiLock magnet is not recognized as a "magnetized material" per IATA (International Air Transportation Association) definition and therefore can be air shipped in bulk quantity.
