Safety Speed Manufacturing offers practical and productivity-enhancing solutions to facilitate shop saw safety for panel size with its extensive array of vertical panel saws. The precision of the cuts made by vertical panel saws on big sheets of material is legendary. The H5 vertical Panel Saw from the H-Series is an affordable full-sized vertical panel saw that can crosscut sheets of material up to 64" wide.
Product Details
A 10' frame made of welded steel
Zinc-coated 1-3/4" steel guide tubes
It can cut every day for up to one to three hours
A 15 amp, 3 1/4 hp, production duty saw motor is included
4 Nylatron roller bearings systems
Horizontal and vertical rulers that can be adjusted quickly
Thin material pressure protection
Rollers made of plastic are injection-molded
Counterbalance system with a spring-loaded action
A built-in 1-½" dust collection hat
Extended Warranty
TUV certified to UL/CSA standards
Item Specifications
Weight: 298lbs.
Dimensions: 120x11x83 in.
Max Crosscut: 64”/1625mm
Max. Rip Cut: Unlimited
Cut Depth: 1-¾" / 45mm
Cut Accuracy: 1/32” / .8mm
Frame Length: 120” / 3050mm
Daily Usage: 1-3 hours
Rollers: 14
Saw Blade Diameter: 8” / 210mm
Motor Amperage and Volt: 15 amps, 120 volt, 7.5 amps, 220 volt
Motor Manufacturer: Milwaukee Tool
Demonstration Video
Safety Speed H-Series Vertical Panel Saws Demo
Transcript :
The popular H models are available in three vertical sizes 50, 64, and 74 inches, depending on your cutting capacity requirements. Each model features a three and a quarter horsepower Milwaukee motor with an ergonomic handle and switch for easy operation and the ability to change from vertical to horizontal cutting in seconds. Adjustable measuring indicators make precision cuts a snap, also included is a thin material pressure guard combined with the proper saw blade. It improves cut performance when cutting thin classics and laminates. A heavy-duty counterbalance neutralizes the weight of the ...
The popular H models are available in three vertical sizes 50, 64, and 74 inches, depending on your cutting capacity requirements. Each model features a three and a quarter horsepower Milwaukee motor with an ergonomic handle and switch for easy operation and the ability to change from vertical to horizontal cutting in seconds. Adjustable measuring indicators make precision cuts a snap, also included is a thin material pressure guard combined with the proper saw blade. It improves cut performance when cutting thin classics and laminates. A heavy-duty counterbalance neutralizes the weight of the saw during vertical cutting, the holder conveniently keeps the cord out of the operator's way, this process is further improved with patented graphite nylon rolling bearings that promote smooth movement of the saw carriage. No lubrication is required and the inherent design of these bearings is impervious to sawdust buildup. The frame is also designed with material rollers spaced to eliminate sawdust buildup a removable upper blade guard with dust port allows standard 8-inch blades with a 5/8 inch arbor to be changed quickly. Twin spring-loaded indexing pins assure positive locking of the power unit in the desired position. With three different cross cutting capacities, a cutting accuracy within 1/32 of an inch, and the ability to cut unlimited lengths on the 10-foot welded frames. The H models are the space-saving profit-making solution for many companies. Don't forget to customize your machine with our full range of accessories and accessory packages to maximize the productivity and versatility of your panel saw.
