Safety Speed SR5A ACM 62" Panel Saw and Router Combo
7399 NewCondition InStock

Safety Speed SR5A ACM 62" Panel Saw and Router Combo

Part #: SS-SR5AACM
Brand: Safety Speed
  • Max. Crosscut: 62" (1575 mm)
  • Max. Rip Cut: Unlimited
  • Max. Cut Thickness: 1 3/4" (44mm)
  • Cut Accuracy, Straight & Square: 1/64" (.4mm)
Select an optional add-on product to further expand the use of the machine. The above price will reflect the additional cost of the add-on. Need more than one accessory? Give us a call so we can customize your order.
Some materials are notoriously ruff on blades, and the blades may need to be changed often for clean cuts. Be ready, and add the proper replacement blades to your order. Only one is selectable from this list, but all are purchasable on our site separately.
  • 1 Year Manufacturer Warranty
  • Price Match Guarantee
  • Oversize / Truck shipping
  • Brand New

$7,399.00

Buy Now - Pay Later

From $684.41 a month

with Credit Key

This Item Ships Via Truck
SWIPE FOR MORE IMAGES
  • 0
  • 1

Product Description

The Safety Speed SR5A ACM is a vertical panel saw and router all in one. It is designed for accurate cutting and V-Grooving of ACM (Aluminum Composite Material) panels. It is featured with a unique floating router with a nylon guide guaranteeing a consistent depth of cut. Engineered with efficiency in mind, the saw can also be switched over to a router in less than one minute. It also features a dust system in place to collect debris while cutting and routing. This panel saw can crosscut up to 62" wide with unlimited rip cut, and can cut materials up to 1-3/4" thick. It is also equipped with a midway fence which makes smaller panel processing much easier. Fabricate ACM Panels with ease with Safety Speed SR5A ACM Panel Saw and Router Combo.

Product Details

  • 3 1/4 Hp, 15 amp industrial duty saw motor.
  • 1 3/4 Hp, 11 amp industrial duty router motor.
  • 10 ft. Welded steel frame.
  • Chrome plated 1 3/4" guide tubes.
  • 8 Nylatron roller bearing systems.
  • Adjustable vertical and horizontal rulers.
  • Quick change from vertical and horizontal cutting.
  • Thin material pressure guard.
  • Injection molded plastic material rollers.
  • Counterweight system.
  • Adjustable floating router head.
  • MID-WAY FENCE™ with stop.
  • 4 material clamps.
  • 2 blind dado stops.
  • Wheels.
  • Fixed Stand.
  • Extensions.
  • Left and right quick stop gauges.
  • Midway Fence Flip Stop
  • Dust hood and hose kit.
  • Hold down bar.
  • Specialty saw blade and router bit for v-grooving.
  • 1 year parts warranty.

Product Reviews

Write Your Own Review
You're reviewing:Safety Speed SR5A ACM 62" Panel Saw and Router Combo
Your Rating

Item Specifications

  • Max. Crosscut: 62" (1575 mm)
  • Max. Rip Cut: Unlimited
  • Max. Cut Thickness: 1 3/4" (44mm)
  • Cut Accuracy, Straight & Square: 1/64" (.4mm)
  • Saw Blade Diameter: 8" (200mm)
  • Motor: 15 amp, 120V, 220V
  • Router: 11 amp, 120V, 220V
  • Frame Length: 120" (3050mm)
  • Shipping Weight: 636 lbs (248 kg)
  • Dimensions: 120 × 17 × 92 in
