Safety Speed SR5A ACM 62" Panel Saw and Router Combo
Flexible Financing for Businesses
Qualifying businesses can get the equipment and supplies they need with Pay Over Time or Enterprise Net 30 payment options.
Easy-Apply at Checkout
Just add to cart & continue to checkout
- Max. Crosscut: 62" (1575 mm)
- Max. Rip Cut: Unlimited
- Max. Cut Thickness: 1 3/4" (44mm)
- Cut Accuracy, Straight & Square: 1/64" (.4mm)
ProductDescription
The Safety Speed SR5A ACM is a combined vertical panel saw and router. It is made to precisely cut and groove ACM (Aluminum Composite Material) panels. It has a special floating router with a nylon guide that ensures a constant cut depth. The saw was designed with efficiency in mind, and it just takes a minute to convert it to a router. Additionally, it has a dust collection system in place to catch waste when routing and cutting. With an endless number of rip cuts, this panel saw can crosscut materials up to 62" wide and up to 1-3/4" thick. Additionally, it has a halfway border, which makes processing smaller panels much simpler. With the Safety Speed SR5A ACM Panel Saw and Router Combo, you can easily fabricate ACM panels.
Product Details
- 3 1/4 Hp, 15 amp industrial duty saw motor.
- 1 3/4 Hp, 11 amp industrial duty router motor.
- 10 ft. Welded steel frame.
- Chrome plated 1 3/4" guide tubes.
- 8 Nylatron roller bearing systems.
- Adjustable vertical and horizontal rulers.
- Quick change from vertical and horizontal cutting.
- Thin material pressure guard.
- Injection molded plastic material rollers.
- Counterweight system.
- Adjustable floating router head.
- MID-WAY FENCEâ„¢ with stop.
- 4 material clamps.
- 2 blind dado stops.
- Wheels.
- Fixed Stand.
- Extensions.
- Left and right quick stop gauges.
- Midway Fence Flip Stop
- Dust hood and hose kit.
- Hold down bar.
- Specialty saw blade and router bit for v-grooving.
- 1 year parts Manufacturer's Warranty.
Item Specifications
- Max. Crosscut: 62" (1575 mm)
- Max. Rip Cut: Unlimited
- Max. Cut Thickness: 1-3/4" (44mm)
- Cut Accuracy, Straight & Square: 1/64" (.4mm)
- Saw Blade Diameter: 8" (200mm)
- Max Blade Speed: 5,800 RPM
- Cutting Direction: Horizontal, Vertical
- Blade Guard: Removable
- Panel Saw Type: Saw/Router Combination
- Current: 11A/15A
- Motor: 15 amp, 120V, 220V
- Voltage: 120V AC
- Amps @ 120V: 13.0
- Horsepower: 1.3/3.3
- Router: 11 amp, 120V, 220V
- Arbor Size: 5/8”
- Frame Length: 120" (3050mm)
- Shipping Weight: 636 lbs (248 kg)
- Dimensions: 17”w x 124” x 92”h
- Corded/Cordless: Corded
- Cord Length: 20ft
- No Load RPM: 5800
