Based on the best selling WireMac (which has the option of 3:1 and 2:1 Model), the WireMac-Duo has both die sets installed in one single unit, with no need to change dies. This new Wire Binding System is all you need to wire punch and bind from 2 sheets to over 200 sheets! The Akiles WireMac Duo Combo Twin Loop Wire Binding Machine is the only machine available on the market that can punch and close both 2:1 and 3:1 pitch wire binding patterns. Built on the same great platform as the best selling Akiles WireMac the WireMac Duo allows you to bind books up to 14" wide and up to 1-1/4" thick.
Product Details
Punches and Closes both 3:1 AND 2:1 Pitch Wires
20 sheets single punching capacity (20 lbs paper)
14" width punching capacity with open sides for even wider documents
All dies can be independently disengaged, to allow the punching of any size document while preventing partial side-end perforation.
Closing capacity: From 3/16" to 1-1/4"
All metal construction
Limited 1 Year Manufacturer's Warranty
Item Specifications
Punching Pitch: 3:1, 3 holes per 1" / 2:1, 2 holes per 1"
Disengageable Dies: 40 dies / 27 dies
Punching Holes: Square 4mm x 4mm / Rectangular 4mm x 5.5mm
Binding Capacity: 3/16" - 9/16" / 5/8 - 1-1/4"
Punching Length: 14" with open throats for longer documents.
Punching Capacity: 20 sheets of 20 lbs bond paper
Die Disengagement Pins: For a clean and complete punching with different paper sizes.
Continuous Punch Guide (3:1 Only) & Open Throats: For punching documents larger than 14".
Depth Margin Controls: Provides the correct punching margin depth needed for all wire sizes and maximizes the document's tear resistance.
Side Margin Controls: Provides a well-centered punch for all document sizes.
Diameter Scale: Measures document's thickness in order to select best wire size option.
Wire Closer Control: Adjusts the wire closer to close wires from 3/16" to 1-1/4"
Closing Mechanism: Vertical
Wire Snatch: Holds wire in place for easier inserting of sheets.
Manufacturer's Warranty: 1 Year Manufacturer
Weight & Cubit Feet : 53 Lbs & 2.22 CbFt
Demonstration Video
Akiles Wiremac-duo Combo Wire Binding Machine Demo Video
Transcript :
Welcome to MyBinding video. This is the Akiles WireMac-Duo combo wire binding machine. First, here's a look at the difference between 3:1 and 2:1 wire. To start using the machine, take your book pages and measure them in the front slots. The ones that fits in first is the size of wire you should use. Then place your wire binding in the holder below. Adjust the knob on the left to the correct size paper and make sure you're using the correct pitch size. Next, adjust your margins for either larger or smaller projects. It's good to place a test page in first, then adjust the disengageable dies so ...
Welcome to MyBinding video. This is the Akiles WireMac-Duo combo wire binding machine. First, here's a look at the difference between 3:1 and 2:1 wire. To start using the machine, take your book pages and measure them in the front slots. The ones that fits in first is the size of wire you should use. Then place your wire binding in the holder below. Adjust the knob on the left to the correct size paper and make sure you're using the correct pitch size. Next, adjust your margins for either larger or smaller projects. It's good to place a test page in first, then adjust the disengageable dies so your punches are even on both sides. Pull the correct lever down to make your punches. You can then place your finished pages into the binding as you go. This is convenient for larger projects since the machine can only punch 20 pages at a time. Next, twist the black knob on the right to the appropriate size wire you're using. you can see what size it is at on the front. Then remove the book from the front rack. Place the open end of the wire down into the wire press. Firmly pull the lever on the left to finish the binding process. And then you have a finished book. In a quick note, that little bump on the right is a guide for when you're using longer paper. And here's an extra little tip for presenting your book. Place your back cover facing your front cover, then thread them into the binding together. That way when you flip it back to normal, the back cover hides the opening end of the binding and holds it in place. That is the Akiles WireMac-Duo combo wire binding machine. For more demos, reviews and how-to's, go to MyBinding.com.
It seems that Akiles has looked to fill a gap in the marketplace with the WireMac Duo. As the only machine available to consumers that can bind documents with either a two to one or three to one pitch hole pattern, the WireMac Duo offers users some unprecedented flexibility. Here are some of the strengths and weaknesses of this machine as we see them.
Strengths:
Of course one of the WireMac Duo’s biggest strengths is its ability to punch in either a two to one or three to one pitch ratio. If you consider that you can use the three to one pitch punch with wire-o, spiral coil, or GBC Proclick, and that the two to one pitch punch can utilize double loop and spiral coil, you actually have the possibility of five separate binding styles with the WireMac Duo. That is a lot of flexibility for a machine at this price point, and perhaps one of the reasons the WireMac Duo seems to be growing in popularity.
This machine features a pair of punching throats, each of them 14 inches in length. What this gives you is the ability to punch any document that is legal sized or smaller. While this is a great capacity, it is important to note that the open throat design and the fully disengageable dies of the WireMac Duo mean that you can punch documents that are larger by using a two punch process.
The WireMac Duo has a nice little system in place for setting the depth at which you punch you holes. It is very easy to use, and will help you ensure the strength and usability of the books that you are producing.
We really liked the inclusion of the wire closing mechanism on the WireMac Duo, and were especially impressed with the heavy duty construction that it features. It is clearly designed to last for years. Plus, the wire hanging hooks that are also on the front of the machine provide a very efficient system for adding pages onto your wire binding spines before you close them.
Weaknesses:
Although this machine can be used to bind documents with both three to one and 0.400 pitch coils, these supplies can be a difficult to get a hold of. In fact, they can take a few days to produce so you will want to make sure you stay on top of your supply ordering process.
The WireMac Duo has a ton of great features, but with that comes, of course, a little bit of a learning curve for inexperienced users. This is a machine has a lot of buttons, handles, and knobs, and if you have never operated and kind of binding machine before you may be a little bit confused. This is not something that should dissuade you from purchasing the WireMac Duo, just something that you should be aware of. Once you get the hang of this machine, you should have no problems at all.
This machine offers great flexibility but it is still a manual binding system. High volume users may want to consider purchasing an electric binding system or a modular binding punch to increase productivity.
Recommended for you
Navigating through the elements of the carousel is possible using the tab key. You can skip the carousel or go straight to carousel navigation using the skip links.
Press to skip carousel
Thank you for your question. We are able to order parts for you directly from the manufacturer. If you do not have the part numbers Akiles would be able assist. Their direct dial phone number is 800-453-3997. Because parts are not able to be returned we like our customers to work directly with the manufacturer to be sure the correct part is being ordered. Some manufacturer's do not sell directly to the public. If you are not able to purchase the part directly from the manufacturer, we are able to order that for you with the part number. Give our customer service department a call at 1-800-944-4573 and we can help you get the process started.
Unfortunately there is not a way to open Wire once it is closed. You can use wire cutters to clip the wire but these are not an editable bind. I do apologize. If you are looking for something that can edit, you may want to try Proclicks that also work with the same wire punch pattern.
Thank you for your question. The Akiles WireMac-Duo Combo Wire Binding Machine would be able to punch a 80# card stock. It would be able to do a couple at a time. The capacities for it's ratings are based of a different weight of stock so unfortunately we do not have a exact number of sheets.
