Product Description
The Challenge 200 TC hydraulic programmable paper cutter with 10.5" Color Touch Screen is one of the highest quality 20 inch fully automatic paper cutters available anywhere. This model uses a light beam safety mechanism to prevent the cutter from operating if a hand or body part is in the cutting area. This wonderful piece of equipment offers a user friendly menu-driven LCD screen and fully programmable backgauge control with 99 channels of memory. It allows you to enter cutting dimensions in fraction, decimal or in metric measurements. It also has a precise light line cut position indicator, table slot closure device as well as hydraulic cutting and clamping for precise cutting every time. The titan 200 also includes a wide variety of safety features making it one of the safest programmable paper cutters available on the market.
Product Details
- Key Benefits/Features:
- User-friendly menu-driven LCD screen, fully programmable backgauge control with 99 channels, 9,801 total cut memory
- Variable mode data entry (fraction, decimal, metric)
- Automatic fraction to decimal calculation
- Electronic Clamp Pressure Control - (programmable per cut with TC option)
- Maintenance free red LED cut line light
- Table slot closure device
- Hydraulic cutting & clamping - motor runs only during cutting cycle
- Rugged steel & cast iron construction
- Lockable heavy duty casters for portability
- Top of machine offers large 14.5" x 36"/36.8 cm x 91 cm) work surface
- 2-year Manufacturer's Warranty
- Safety/Features:
- UL/cUL listed and conforms to CE and ANSI B65.3 safety specifications
- Two-hand push button control of cutting cycle with timed, non-repeat device
- Cutting area protection - choice of light beam safety curtain or Plexiglas shield
- Independent mechanical foot pedal clamping
- Fully enclosed sheet metal rear table safety cover
- Optional ergo-touch cut buttons reduce operator fatigue
- Included:
- (2) high speed steel knives
- (3) plastic cutting sticks
- (1) jogging aid
- (1) manual
- (1) tool kit
- (1) knife change safety holder assembly
Specifications
- Cutting Width: 20”/508 mm
- Clamp Opening: 3-1/4”/83 mm
- Clamping Force:
- Minimum 1,250 lbs/563 daN
- Maximum 2,500 lbs/1,125 daN
- Min Cut (w/out false clamp plate): 1/2”/13 mm
- Min Cut (with false clamp plate: 1-7/8”/48 mm
- Table:
- In Front of Knife 15-1/4“/387 mm
- Behind Knife 20”/508 mm
- Table Height: 36”/914 mm
- Metal side tables (light beam only): 12.2”x8.2”/310x208mm
- Overall Width: 39-5/8”/1006 mm
- Overall Length: 50-7/8”/1293 mm
- Overall Height: 53”/1350 mm
- Will pass through door:
- (assembled) 39-3/4”/1010 mm
- (side tables, light beams, & power switch out) 36-1/4”/920 mm
- (table/treadle/light beams out) 29”/737 mm
- Net Weight (approx.): 800 lbs/363 kg
- Shipping Weight (approx.): 980 lbs/444 kg
- Electrical UL/CUL Listed & CE:
- 1 1/2 H.P., Single-Phase, AC, 60 Hz, 208/230 Volts, 12 Amps, Service size 15 Amps. Power cord included. Requires Receptacle Type: NEMA 6-15R or 6-20R.
Replacement Blades and Accessories
| Product Name | Item Number |
| Challenge 20 Multi 2020 Titan 200 Replacement Blade | JH-31780 |
| Challenge 20 Multi 2020 Titan 200 High Speed Steel Blade | JH-31780HSS |
| Premium 20" Cutting Stick for Challenge 20, Titan 200, Multicut 2020 | JH-CS4075 |
| Standard 20" Cutting Stick for Challenge 20, Titan 200, Multicut 2020 | JH-CS4168 |
| Red Premium Cutting Stick for Challenge 20, Titan 200, Multicut 2020 | JH-CS5910 |
