SKU
PRODUCT NAME
PRICE
QUANTITY
04HIXREPKITE1620
$352.00
Product Description
Get the coverage your designs need with the HIX S-650 auto-open clamshell heat press. This outstanding press opens automatically without the need of an air compressor. It’s the perfect press for high traffic, high volume, and increased productivity. The S-650 utilizes an electronically activated mechanical latch release mechanism with a gas shock assist to help enhance and support your operations. This helps to reduce fatigue and increase productivity. Direct-To-Garment applications are also a large driving force in the success of the auto-open feature, allowing you the freedom of loading your printer while the last print is curing, eliminating any risk of scorching or compromising transfer quality due to overheating.
Product Details
- Dimensions: W 21" x H 23" x D 33"
- Heat Platen Size: 16" x 20" (41 x 51 cm)
- Weight Shipping: 95 lbs. (43 kg)
- Compatible Accessories:
- Interchangeable Padded 13 x 13 Lower Platen
- Interchangeable Padded 15 x 15 Lower Platen
- Interchangeable Padded 16 x 20 Lower Platen
- Interchangeable Padded 4-Position Lower Platen (two-6x5" & two-3.5x3.5" areas)
- 16" x 20" PTFE Pad Protector Deluxe
- 15" x 15" PTFE Transfer Sheet
- 16" x 20" PTFE Transfer Sheet
- 16" x 20" - 1/2" Thick Premier Series Pad Replacement Kit
- 16" x 20" - 1/2" Thick EVO Series Pad Replacement Kit
- Optional Splitter Stand - Electric Blue
- Warranty: Lifetime Manufacturer's Warranty on the heater element / 1 Year Manufacturer's Warranty General
- Old Part Number:MY04HIXS650P
Specifications
- Easy integrated digital time and temperature settings - Touch-screen controller access allows simple dialing in of time and temperature. From the touch-screen controller, preset selections of temperature-time combinations can be easily programmed into the machine.
- The current pressure is displayed on the touch-screen display each time the press closes. The pressure is easily changed by turning the silver knob at the top of the control housing (clockwise for more, counter-clockwise for less). There are nine settings on the display: 0-3 for light pressure, 4-6 for medium, and 7-9 for heavy pressure.
- Tilting (floating) lower platen - The bottom platen tilts up towards the upper platen as the heat press closes. This equalizes pressure, even when pressing thick items like a quarter-inch thick 8×10 ceramic tile.
- Top Pressure Plate- The handle attaches to a 4"x 5" pressure plate on the top platen instead of a single screw going into the top platen. This provides more even pressure on the outside edges of the press (think of it as pushing down with your entire hand, versus just your thumb).
- Certified electrically safe (ETL) - The “Electrical Testing Laboratory" seal means HIX presses have passed a rigid and demanding independent testing process, and have been certified electrically safe.
- 100% Made in the USA - HIX has its own 11,000 sq ft manufacturing facility with its very own fully integrated aluminum foundry, CNC mill operation, welding, metal forming, wiring, fabrication, assembly, and packaging departments.
- A one-year general manufacturer's warranty and lifetime manufacturer's warranty on the heater element.
