MediaShield Heatset Mattex UV 3mil Overlaminate

$1,026.04

Price Match Guarantee*

Need Shopping Advice?
Call - (800)944-4573

Versatile hybrid design combines thermal and pressure-sensitive properties for seamless application on various media.
Exceptional satin matte finish enhances color vibrancy while reducing glare, perfect for high-impact graphics.
Quick setup and curing time allow for immediate handling, streamlining your workflow and increasing productivity.
Robust construction enables flush trimming and die-cutting without delamination, ensuring professional results every time.

SKU

PRODUCT NAME

PRICE

QUANTITY

MX51328

51" x 328' 3mil MediaShield Heatset Mattex UV Overlaminate (Satin Matte, 3" Core) - 1 Roll

$1,026.04

Product Description

MediaShield Mattex UV 3mil is an extremely versatile Heat-Set overlaminating film that adds a desirable satin matte finish without sacrificing color definition. The soft non-reflective finish of MediaShield Mattex UV makes it the film of choice for direct lit graphics. On inkjet images for trade show and POP displays, MediaShield Mattex cuts glare without sacrificing color detail. Also use MediaShield Mattex UV to laminate inkjet output printed on canvas. Because the film is thin and pliable, it conforms well to canvas weave, maintaining texture while offering excellent protection.

Product Details

A hybrid between thermal and pressure sensitive films.
Co-extruded for a carefully balanced ratio of polyester film to adhesive.
Bond well to inkjet output with high ink coverage - even on photo gloss paper and digital photo laser output (Lambda / Lightjet).
Image can be trimmed flush, or even die-cut without fear of delamination.
Due to its quick setup / curing time, MediaShield laminated graphics can be handled or rolled immediately after processing.
Protected by a release liner because the adhesive on these films is slightly tacky when cool.

Specifications

Film Width: 38" - 55"
Film Length: 164' - 328''
Film Thickness: 3.0mil
Core Size: 3"
Finish: Satin-Matte
Base Film: 2.0mil (50 micron) PVC (vinyl)
Adhesive: 1.0mil (25 micron) solvent acrylic
Initial Tack: Low
Application Speed: 1' - 6' per minute
Application Temperature: 185 F - 210 F
Release Liner: Moisture Stable Paper (70gsm)
Compatible Equipment: 3" Core Thermal Roll Laminators

Technical Data

MediaShield Mattex is a 2 mil (50µ) phthalate-free, UV stabilized, clear PVC laminating fi lm with a satin matte finish, coated on one side with a heat activated solvent acrylic adhesive that is protected by a moisture stable bleached Kraft gridded release paper coated on one side with siliconized PE.

Typical Applications

The film’s soft, non-refl ective finish makes it ideal for direct graphics.
When used on inkjet images for tradeshows and POS displays, it will cut glare without sacrifi cing color detail.
Can be used to laminate inkjet output printed on canvas.
As the film is thin and pliable, it conforms well to canvas weave, maintaining its texture.

Product Structure

Film	Satin Matte PVC
Adhesive	Solvent Acrylic (Heat Activated)
Release Liner	1 Side PE Coated Bleached Kraft Grid Paper (Moisture Stable)

Physical Characteristics

Film Thickness	2 mil (50µ)
Adhesive Layer	1 mil (25µ)
Film/Adhesive Ratio	2:1
UV Protection Factor	Film contains UV stabilizers, which prevent film degradation and provide UV protection to the underlying image
Outdoor Durability	Not Applicable
Service Temperature Range	-4°F to 203°F (-20°C to 95°C)
Peel Strength (20 min, FTM1)	18 N/25mm
Shelf Life	Use within 1 year after opening original box
Storage Conditions	59°F to 72°F (15°C to 22°C); 50 - 55% Relative Humidity

Process Settings

Equipment Type	Temperature	Speed
Roller Laminator	185°F to 215°F (85°C to 102°C)	1 ft to 8 ft (0.3m to 2.5m) per minute
Press	185°F to 210°F (85°C to 99°C) Dwell Time: 2-8 minutes

Downloadable Information

Technical Data Sheet
Sales Literature
