Product Description
To Get the Full Package, Order All of the Items Above The Rhin-O-Tuff 4012W3 is a medium duty electric 3:1 wire binding system from Rhin-O-Tuff. The 4012W3 can easily punch up to 30 sheets of 20# paper can be punched at one time with perfect and align holes Everything you need to produce 3:1 wire binding is included in this system except for your wire and covers, those you can purchase separately for easy customization. The medium duty 4012W3 system contains the 4012 modular binding punch, a 3:1 square hole die ( .333 hole spacing - .156 square hole size), a 14" manual flat bar wire inserter and closer, and a modular mounting kit. Manual and auto-reversing structures eliminating the word "jam" out of this system.
Product Details
- Model: OD4012 Onyx
- Wire Die: 74231A 3:1 Square .333 hole spacing - .156 square hole size
- Wire Inserter : 8000 ONYX 14" manual flat bar wire inserter / closer
- Punch Capacity Up to 30 Sheets of 20 lb paper
- Punch Length: 11" Punching Length with Open Ended Extra Capacity Die
- Fully Disengageable Pins:Yes
- Weight: 80 lbs
- Machine Dimensions: 15" x 21 3/4" x 19 3/4" (H x W x D)
- Manufacturer's Warranty: Three Year Manufacturer's Warranty (1 year on the punching die)
- Compatible Supplies: 3:1 Pitch Twin Loop Wire
Specifications
- 3:1 Wire Die with easy disengageable pins - Included
- 14" manual flat bar wire inserter - Included
- Attachment kit for mounting wire inserter on top of punch - Included
- Automatic and Manual Reverse feature to reduce jamming in the punch
- Punches up to 30 sheets of 20 lb paper
- Rate of 25 cycles per minute
- Auto and manual reverse clears most punching jams
- Accu-Set adjustments on odd size paper
- Efficient work environment with a standard foot pedal and optional versa switch
- Extreme high capacity Waste Chip Tray with Clear View Access
- Heavyweight metal construction
- Made in the USA with more than 98% recyclable materials
