Product Description
This WindowTac 54" x 164' Pressure Sensitive Mounting Adhesive is a 0.9 mil visually clear PET film, coated on one side with a pressure sensitive, removable adhesive that is protected by a microgrooved PE release liner that imparts an embossed pattern onto the adhesive coating. The other side is coated with a pressure sensitive, aggressive permanent adhesive that is protected by a bleached Kraft release paper coated on both sides with PE and siliconised on the release side. The film contains UV stabilisers, which protect against UV degradation, and the micro-grooves in its adhesive allow for easy air evacuation. WindowTac film is recommended for face mounting graphics onto glass, acrylic, and other non-prous surface. It can also be used for backlit displays. Get 1 roll on every order of WindowTac 54" x 164' Pressure Sensitive Mounting Adhesive.
Product Details
- Compatible Equipment: 3" Core Pressure Sensitive Roll Laminators
Specifications
- Clear, double-sided mounting adhesive with an embossed release liner
- Micro-grooves in the removable adhesive allow for easy air evacuation with a squeegee
- Excellent clarity without bubbles or wrinkling
- Provides additional UV protection for graphics printed with dye-based or pigmented inks
Features:
- Transforms any printed image into an easy-to-install window graphic or decal
- Graphics can be dry installed, cleanly removed and easily repositioned during installation
- Suitable for double-sided window graphics
- Ideal for face mounting of temporary graphics to glass, acrylic and other non-porous surfaces
- Ideal for short-term promotional window advertising and POP displays
Benefits:
Technical Data
WindowTac is a 0.9 mil (23µ) visually clear PET film, coated on one side with a pressure sensitive, removable adhesive that is protected by a micro-grooved PE release liner that imparts an embossed pattern onto the adhesive coating. The other side is coated with a pressure sensitive, aggressive permanent adhesive that is protected by a bleached Kraft release paper coated on both sides with PE and siliconized on the release side. The film contains UV stabilizers, which protect against UV degradation, and the micro-grooves in its adhesive allow for easy air evacuation.Typical Applications
- Recommended for face mounting graphics onto glass, acrylic and other non-porous surfaces.
- Can be used for backlit displays.
- Can be re-positioned up to 10 times in the first 12 hours and cleanly removed within 12 months after application.
- Can be used on media printed with all common print technologies, including (Eco) Solvent, Latex and UV.
Product Structure
| Release Liner | 2 Side PE Coated, 1 Side Siliconized Kraft |
|---|---|
| Adhesive | Permanent Acrylic (Pressure Sensitive) |
| Film | Visually Clear PET |
| Release Liner | Embossed HDPE |
Physical Characteristics
| Film Thickness | 0.9 mil (23µ) |
|---|---|
| Adhesive Layer | 1 mil (25µ) permanent 0.6 mil (14µ) removable |
| Film/Adhesive Ratio | 1:0.9:0.6 |
| UV Protection Factor | UV Stable |
| Outdoor Durability | Not Applicable |
| Service Temperature Range | -4°F to 248°F (-20°C to 120°C) |
| Peel Strength (20 min, FTM1) | 22 N/25mm (permanent - glass) 3 N/25mm (removable - glass) |
| Shelf Life | Use within 1 year after opening original box |
| Storage Conditions | 59°F to 72°F (15°C to 22°C); 50 - 55% Relative Humidity |
Process Settings
| Equipment Type | Temperature | Dwell Time |
|---|---|---|
| Roller Laminator | Room temperature to 104°F (40°C) | 1 ft to 8 ft (0.3m to 2.5m) per minute |
| Press | Not recommended | |
Prior to application, clean the mounting substrate with soap and water. Rinse thoroughly with water and wipe dry with a lintfree cloth. Window cleaners are not recommended.
