Standard APC-610 24" Programmable Hydraulic Paper Cutter

Skip to the beginning of the images gallery

SWIPE FOR MORE IMAGES

Product Description

The Standard APC-610 24" Hydraulic Paper Cutter can easily automate paper cutting projects and complete them with accuracy and speed. The machine has a maximum cutting width of 24’’ and a maximum cutting height of 3.9’’. Easy to set up and to use, the paper cutter has a touch-screen display with large 5’’ icons that offer quick access to the automation options. The high-performance back gauge screw, precision-made raceway, and two-speed motor all ensure perfect accuracy. Likewise, the specially made steel blades provide ultra-sharp cutting for longer than standard knives. Made with a chrome-plated work table with a polished finish, the Standard APC-610 24" Hydraulic Paper Cutter eliminates paper marking.

Product Details

Hydraulic clamping and cutting mechanism ensures powerful and accurate cutting quality.
The servo-motor driven backgauge assures accurate positioning and repeatability for consistent quality production.
The color touchscreen is intuitive and icon-based for user-friendly operation. Operation, setting and information screens are used for efficient and accurate operation.
The Simple Program Setting screen displays sheet rotating direction and cutting order graphically.
The APC-610 is activated only when the two cut buttons are simultaneously pressed for operator safety.
The unit comes standard with light curtain area sensors, if they detect any object, the cutting motion will stop immediately. These sensors meet the high level of safety specified in Category 4 according to ISO13849-1.
Double Safety Circuit - The system is further equipped with a hard-wired secondary safety interrupt for operator safety.
The system can be further enhanced with Horizon's pXnet bindery control system which integrates JDF workflow from upstream devices.
The Knife Angle Adjusting Lever are easily done on the front side of the cutter.
Maximum cutting width is 610 mm / 24.0”, maximum cutting height is 100 mm / 3.39”.
The cutting knife is made of special steel ensuring consistently high standard cutting quality for a prolonged period of time.

Item Specifications

Cutting Width: Max - 610 mm / 24.0"
Cutting Height: 100 mm / 3.93" (95 mm / 3.74" using the support plate)
Cutting Depth (Max.): 620 mm / 24.4"
Cutting Depth (Min.): 25 mm / 0.98" (65 mm / 2.56" using support plate)
Clamp System: Hydraulic Powered 50 to 20 kN (500 to 2,000 kgf)
Job Memory: 99 Steps, 200 Jobs
Push-out Length: 20 to 150 mm / 0.785" to 5.905" Adjustable
Cutting Speed: 3.8 seconds per cycle
Rated Current: 3-Phase 200 to 220 V, 50/60 Hz, 8.2 A/ 3-Phase 380/400/415 V, 50/60 Hz, 4.2 A
Machine Dimensions: 45.6" W x 59.3" D x 58" H (1,156 x 506 x 472 mm)
Weight: 1,724.7 (783 kg)
