Rhin-O-Tuff Tornado Autopunch EX Modular Interchangeable Die Binding Punch
29950 NewCondition InStock

Rhin-O-Tuff Tornado Autopunch EX Modular Interchangeable Die Binding Punch

Part #: TEX110
Brand: Rhin-O-Tuff
  • Punched Edge: 8.27" to 12"
  • Unpunched Edge: 5.5" to 12.5"
  • Index Tabs: Up to 1/2" tab extension
  • Interposer Bin Capacity: Up to .75" of Covers/Index Tabs/Insert Sheets
  • Price Match Guarantee
  • Oversize / Truck shipping
  • Brand New
In Stock

$29,950.00

This Item Ships Via Truck
SWIPE FOR MORE IMAGES
  • 0
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
video

Product Description

Say goodbye to manual collation and punching of covers, index tabs and inserts, manual paper lift punching , and manual separation of book stacks after punching with this new Rhin-O-Tuff Tornado Autopunch EX Modular Interchangeable Die Binding Punch. This modular punch uses BDT Print Media’s advanced media handling technology to automatically feed, collate, punch and deliver offset book stacks ready for binding in a single platform. The Tornado Autopunch EX handles media from 60gsm to 312gsm, including light porous/heavy coated print media and specialty binding media like plastics, vinyl, and textures. This automated binding punch can punch up to 10,800 sheets per hour, and its high-capacity main bin holds up to 2500 sheets, (including mixed media). Reduce your labor-intensive punching process and maximize your productivity and profit with Rhin-O-Tuff Tornado Autopunch EX Modular Interchangeable Die Binding Punch.

Product Details

  • World’s First Automated Collating Punch using Patented BDT Tornado Technology. A single off-line automated collation and punching platform to meet the needs of your on-demand print environment with a quick return on investment.
  • Advanced Media Handling Technology. Powered by BDT’s patented Tornado Technology to separate, lift and transport the widest range of media, including printed media and other book components like covers, tabs and inserts reliably minimizing downtime.
  • Widest Media Range in the Industry. The system handles media from 60gsm – 312gsm, including light porous/heavy coated print media and specialty binding media like plastics, vinyl, and textures.
  • Automated Interposing of Covers/Index Tabs/Inserts. Two Interposer Bins hold up to .75" (19mm) of media, auto-collating front/back covers, inserts and index tabs into the book stack prior to punching. No manual collation required.
  • Accommodates Mixed Media Run on Digital/Offset Printers. High-Capacity Main Bin holds up to 2500 sheets, including mixed media.
  • "Patent-Pending" Paper Accumulation Technology. Designed to accumulate covers, tabs and document sheets and auto-adjust the punch lifts depending on the type of media being run for maximum punching performance.
  • Heavy-Duty Auto-Punch Technology. Proven Rhin-O-Tuff technology punches up to 10,800 sheets per hour, improving throughput.
  • Offset Book Stacks Ready for Binding. Book stacks exit collated and ready for binding, enabling operator’s to start the binding process while the punching job is still running, saving time and labor.
  • Eliminate 4 Manual Steps
    • No manual collation of covers, index tabs and inserts
    • No manual punching of covers, index tabs or inserts
    • No manual paper lift punching
    • No manual separation of book stacks after punching - no color slip-sheets by book/section required when printing

Item Specifications

  • 7" Touchscreen Display: 7" Touch function color display Job Set-up and Monitoring - Quick Start Mode, Preset Media Types, Job Status Display Punch/Die Cycle count and Chip Bin Status
  • Sheet Sizes:
    • Punched Edge: 8.27" to 12"
    • Unpunched Edge: 5.5" to 12.5"
    • Index Tabs: Up to 1/2" tab extension
  • Media: 60gsm to 312gsm including - Uncoated Bond Paper, Text/Offset Coated Paper, Plastic (Acetate/PVC) and Vinyl Covers/Tabs (*Plastic media must be run from an Interposer Bin only.)
  • Interposer Bin Capacity: Up to .75" of Covers/Index Tabs/Insert Sheets
  • Main Bin Capacity: Up to 2500 sheets of 20lb. bond
  • Punching Speed: Up to 10,800 Sheet per Hour based upon 20lb. bond
  • Interchangeable Die Sets: LETTER (US) and A4 (INTL) formats in 9 Binding Styles
  • Offset Stacker: Up to 2100 sheets of 20lb bond
  • Weight: 770 lbs.
  • Dimensions (W x D x H): 28" x 59" x 59"
  • Voltage: 115 Volt, 60Hz
  • Warranty and Safety: 1-Year Limited Warranty/UL-CSA Approval

Product Reviews

Write Your Own Review
You're reviewing:Rhin-O-Tuff Tornado Autopunch EX Modular Interchangeable Die Binding Punch
Your Rating

Demonstration Video

Rhin-o-Tuff Tornado Autopunch EX Introduction

Transcript: Rhin-o-Tuff has been and still is on the cutting edge of book binding technology and today Rhin-o-Tuff is proud to introduce the world's first automated collated punch. The Rhin-o- tuff Tornado Autopunch EX for the first time in this industry we have one single machine that can punch numerous types of substrates, insert tabs, collate, and produce numerous punched book blocks ready for binding. Recently we put to a speed test the traditional model and the tornado Autopunch EX system for 75 books with covers and tabs and found that we saved an impressive 57 percent total job done. The manual re ... Read More
Rhin-o-Tuff has been and still is on the cutting edge of book binding technology and today Rhin-o-Tuff is proud to introduce the world's first automated collated punch. The Rhin-o- tuff Tornado Autopunch EX for the first time in this industry we have one single machine that can punch numerous types of substrates, insert tabs, collate, and produce numerous punched book blocks ready for binding. Recently we put to a speed test the traditional model and the tornado Autopunch EX system for 75 books with covers and tabs and found that we saved an impressive 57 percent total job done. The manual removal of slip covers, collating, adding front and back covers, all a thing of the past with the Tornado Autopunch EX. This machine allows you to take all of these processes and combine them into one machine, one function, and allowing the operator to bind books concurrently while the machine continues to punch out new punched book blocks. Welcome to the new way, the world's first collating Autopunch. One printer told us that time is everything, there's a real time savings for a person not having to stand at the machine all of the time. Any type of time savings is outstanding. Punch, sort, stack, punch covers, and insert tabs all in one step with the amazing technology built into this one machine. An operator can stack 2500 sheets of paper in the main bin and the two interposed trays can handle the widest variety of difficult substrates unlike any other machine on the market. And with the patented EX system, the operator can punch one of nine different styles into all of these materials. The main block, front cover, back cover, tabs, no problem. Using the simple graphic user interface panel, the operator can program the entire job and moments later out pops off sets, stacked document sets, ready for easy retrieval and binding. Using an exclusive partnership with German engineering company BDT, Rhin-o- Tuff has harnessed Tornado technology. It all begins with the use of air; side blowers blow air through and across all the substrates reducing static electricity and cling. Built right into this Rhin-o- Tuff machine are these blowers working hard to maximize efficiency and if your eye can even catch it, you can see the side air and Tornado suction working in tandem and the patented rollers keep things moving regardless of the material makeup. Rhin-o-Tuff is combining decades of leading engineering in the binding industry, individual punched die sets allow for multiple binding styles which allows for great versatility, and because of the RFID tag on each die, the Tornado auto punch could automatically read and adjust for the punch style in play. All of this done with one machine that punches and collates automatically. Here are some key features that give the Tornado auto punch EX its versatility and ease of use as the world's first automated correlating punch. It has advanced media handling technology, the widest media range in the industry, automated interposing of index tabs, covers, and inserts. It accommodates mixed media runs on digital printers. Patent-pending paper accumulation technology. Heavy-duty auto-punch technology. Offset book stacks ready for binding. And that is the Tornado Autopunch EX.

Rhin-o-Tuff Tornado Autopunch EX Key Specifications

Transcript: Let’s take a look at the Tornado Autopunch EX key specifications. Tonado can punch book sizes from 8.27”-12 inches on the punched edge and 5.5” – 12.5” on the unpunched edge. Perfect for standard letter and half letter, A4, A5, and 12-inch documents. The EX has 2 separate interposer bins that allow for multiple substrates such as covers and tabs for up to 0.75” per stack. The main bin itself can handle 2,500 sheets of 20lb paper. And although the Tornado punches and collates the same time with multiple substrates in one project, it can turn out 10,800 sheets per hour. The Tornado Autopunch EX ... Read More
Let’s take a look at the Tornado Autopunch EX key specifications. Tonado can punch book sizes from 8.27”-12 inches on the punched edge and 5.5” – 12.5” on the unpunched edge. Perfect for standard letter and half letter, A4, A5, and 12-inch documents. The EX has 2 separate interposer bins that allow for multiple substrates such as covers and tabs for up to 0.75” per stack. The main bin itself can handle 2,500 sheets of 20lb paper. And although the Tornado punches and collates the same time with multiple substrates in one project, it can turn out 10,800 sheets per hour. The Tornado Autopunch EX by Rhin-o-Tuff.

Rhin-o-Tuff Tornado Autopunch EX Advantages

Transcript: Let’s have a look at the advantages of the Tornato-Auto punch-EX. Speed in production efficiency is Tornatos advantage over all other auto punches. On average we see a forty percentage savings in frequent time. A recent time’s test of seventy five books with tabs show that Tornato- Auto punch at fifty seven percent faster than the traditional methods. The automatic coalition of sheets, covers and tabs allows this machine to sore and since the binding process was started before the punching was even finished, fifty seven percent of time was saved. The secret when we add single sheet feeding and ... Read More
Let’s have a look at the advantages of the Tornato-Auto punch-EX. Speed in production efficiency is Tornatos advantage over all other auto punches. On average we see a forty percentage savings in frequent time. A recent time’s test of seventy five books with tabs show that Tornato- Auto punch at fifty seven percent faster than the traditional methods. The automatic coalition of sheets, covers and tabs allows this machine to sore and since the binding process was started before the punching was even finished, fifty seven percent of time was saved. The secret when we add single sheet feeding and Tornato technology you get perfect custom pagination and the work goes even faster when the offset complete stacking enables concurrent binding while the machine can be used to punch and correlate on your behalf. The Tornato-Auto punch-EX advertised.

Die Set Specifications

  • Die Set Styles:
    • 19/21 Hole Plastic Comb
    • 4:1 Color Coil - Round and Oversized Hole (.2475" or 6mm)
    • 3:1 Twin Loop Wire - Squre and Round Hole
    • 2:1 Twin Loop Wire - Squre and Round Hole
    • 11/12 Hole VeloBind
    • Loose-leaf - 3-5-7 Hole and 2-Hole Medical (8.5" side)
    • Loose-leaf - A4 2-4 Hole
  • RFID Chip:
    • Display die set type in LCD Screen
    • Tracks/display # of punch cycles/die set
  • Disengaugeable Punch Pins: Pins pull out for varying paper sizes
  • Machine Storage: Integrated stroage for up to 4 extra die sets
