Matrix MX-530DP 20" Pneumatic Dual Sided Roll Laminator
- 20" automatic roll laminator
- Compatible with film up to 1.7mil thick
- Adjustable heat settings from 176°-284° F
- Up to 396" per minute adjustable speed
ProductDescription
The Matrix 530DP Duplex Pneumatic Laminator is the ideal new laminating machine for anyone who primarily laminates on both sides. The MX530DP, which includes all of the features of the original MX530 as well as pneumatic pressure for faster laminating, will double output speed by laminating both sides of the sheet at the same time. Additionally, it has the added benefit of being able to perform digital foiling, allowing you to easily create stunning metallic and "spot UV" effects!
Product Details
- Key Features:
- Pneumatic Pressure
- Laminate both sides at the same time
- Foil & Spot UV-style effects
- Easy-to-use control panel
- Anti-curl technology
- Semi-automatic feed
- Automatic separator
- Great for use in:
- Commercial printers
- Digital printers
- Copy and print shops
- Ideally suited for:
- Business cards
- Menus
- Book covers
- Brochures
- Flyers
- and many more...
Item Specifications
- Max. Mechanical Speed (m/ft/min): 10m/33ft
- Max. Lamination Film Width (mm/inches): 500mm/20"
- Minimum Paper Thickness (gsm/lbs): 100gsm/68lbs
- Maximum Sheet Width (mm/inches): 550gsm/22"
- Warm-up Time (mins): 10
- Temperature Range (°C/°F): 0-140°C/32-284°F
- Power Supply (V): 208/220
- Power Supply Required (Amps): 30
- Power Consumption (W): 4500
- Overall Dimensions (mm/inches): 900x2050x1400mm/35x81x55"
- Gross Machine Weight (kg/lbs): 250kg/550lbs
- Warranty: 1 Year
- Part Number:MX-530DP
Demonstration Video
Matrix Mx-530DB 20" Pneumatic Dual Sided Roll Laminator
The Vivid Matrix MX-530DP can be operated in three different ways. You can do single side lamination, double side lamination, and encapsulation.
The machine is designed in Great Britain, and the control panel is simple to use, even for a multilingual environment.
There is a simple pressure adjustment knob, and the pneumatic rollers allow the matrix to run up to twice the speed of standard systems. This results in a significantly faster production time. Depending on the substrate, this could me 50% faster.
...
The Vivid Matrix MX-530DP can be operated in three different ways. You can do single side lamination, double side lamination, and encapsulation.
The machine is designed in Great Britain, and the control panel is simple to use, even for a multilingual environment.
There is a simple pressure adjustment knob, and the pneumatic rollers allow the matrix to run up to twice the speed of standard systems. This results in a significantly faster production time. Depending on the substrate, this could me 50% faster.
For single side lamination, select to use only the top roller. This is quick and cost effect.
Or choose to do double sided lamination. With this method you can use different combinations of laminates—mattes and glosses on one side or both sides. To change a roller, simply attach the film to the old film and run it through the machine!
Actual laminating should not be use for preservation projects—it’s best used for short term uses as it is destructive to your materials over time.
Lucky, this machine also does Encapsulation, which is best for long term preservations. Switch out to the proper rolls and begin to safely protect your projects from the environment.
The 530DP has some great options and features that set it apart from other laminators.
Compare to Similar Matrix Roll Laminators
Model Name | Matrix MX-370P | Matrix MX-530P | Matrix 370DP | Matrix MX-530DP |
---|---|---|---|---|
Model | ||||
Max. Laminating Speed | 33 feet/min | 33 feet/min | 33 feet/min | 33 feet/min |
Max. Width | 13 inches | 20 inches | 17 inches | 22 inches |
Paper Thickness | 90 lbs | 90 lbs | 68 lbs | 68 lbs |
Warm-Up Time | 10 mins | 10 mins | 10 mins | 10 mins |
Laminating Temperature Range | 32-284°F | 32-284°F | 32-284°F | 32-284°F |
Film Core | 3 inches | 3 inches | N/A | N/A |
Power Consumption | 2200 W | 2400 W | 4500 W | 4500 W |
Dimensions (W x D x H) | 31" x 71" x 55" | 35" x 81" x 55" | 31" x 71" x 55" | 35" x 81" x 55" |
Warranty | 1 Year Manufacturer's Warranty | 1 Year Manufacturer's Warranty | 1 Year Manufacturer's Warranty | 1 Year Manufacturer's Warranty |
