Name: Formax Cut-True 29H 20.5" Hydraulic Programmable Guillotine Cutter
Brand: Formax
SKU: Cut-True 29H
Rating: 5.0 (1 reviews)

Formax Cut-True 29H 20.5" Hydraulic Programmable Guillotine Cutter

$23,745.25

Price Match Guarantee*

Quantity

Need Shopping Advice?
Call - (800)944-4573

Item# Cut-True 29H

Cutting Action: Dual-button hydraulic
Maximum Cutting Width: 20.5" (520mm)
Programmable Jobs: Up to 100 programs with up to 100 steps each
Touchscreen Features: Program jobs, alternate between inches/mm, paper eject function, programming via cutting, business card cutting mode

SKU

PRODUCT NAME

PRICE

QUANTITY

FDCT29-10

Replacement Blade for Formax Cut-True 29A and 29H Cutters

$575.00

FDCT29-20

Cutting Sticks for Formax Cut-True 29A and 29H Cutters - 12pk

$150.00

STFCT29-30

Side Tables for Formax Cut-True 29A and 29H Cutters - 1 Pair

$895.00

Product Description

The Formax Cut-True 29H Hydraulic Guillotine Paper Cutter delivers precise cutting for stacks up to 3.15" high and 20.5" wide, featuring a touchscreen control panel, automated back gauge positioning, 100-job memory, adjustable hydraulic clamp pressure, and a bright LED cutting line for exact alignment. The foot-pedal pre-clamp allows operators to verify position before cutting, while electronically controlled two-hand operation and a hardened steel blade ensure crisp, accurate results every time. Safety is built-in through an infrared light curtain, transparent guards, blade lock, key lock, external blade depth adjustment, automatic blade return, and a wooden paper push for safe alignment. Its anti-friction work surface, optional wide side tables, removable false clamp, and internal cutting-area light enhance usability and support handling of large or delicate stock. Ideal for high-volume print finishing, the Cut-True 29H offers robust performance, industrial reliability, and clean professional results plus, replacement blades and cutting sticks are available as accessories to maintain long-term cutting precision.

Product Details

Cutting Action: Dual-button hydraulic

Cut Capacity: 700 Sheets

Maximum Cutting Width: 20.5" (520mm)

Maximum Paper Stack Height: 3.15" (80mm)

Programmable Jobs: Up to 100 programs with up to 100 steps each

Touchscreen Features: Program jobs, alternate between inches/mm, paper eject function, programming via cutting, business card cutting mode

Length Behind Blade: 20.5" (520mm)

Length in Front of Blade: 18.25" (464mm)

Minimum Cut w/False Clamp: 2.36" (60mm)

Minimum Cut w/o False Clamp: 1.18" (30mm)

Table Size: 30.75" W x 15.75" D ( 781x 400mm) or 56" W x 15.75" D (1422 x 400mm) w/ optional wide side tables

Clamp Style: Automatic, hydraulic

Hydraulic Clamp Pressure: 700 - 4,500 psi (49 - 316 kg/cm2)

Back Gauge Adjustment: Fully programmable using touchscreen, accurate to 0.1mm

Blade Change Safety Tool: Included

Dimensions: 49.2" H x 36.75" W x 53.2" D (1250mm H x 934mm W x 1352mm D)

Dimensions w/Optional side tables: 49.2" H x 61.5" W x 53.2" D (1250mm H x 1563mm W x 1352mm D)

Weight: 1,014 lbs. (460kg)

Power Supply: 230V, 50Hz, 20A dedicated line NEMA Plug: 6-20

Manufacturer's Warranty:

90 day limited Manufacturer's Warranty on parts.
Excluding wearables and labor.

Specifications

Hardened Steel Blade: Designed for accurate cuts and long life

Hydraulically-Controlled: Adjustable hydraulics control paper clamp and blade carrier

False Clamp: Minimizes marking of sensitive paper stock, easily stores within the machine when not in use

Touchscreen Control Panel: Easily set, adjust and program jobs

LED Cutting Line: Bright red LED line indicates exactly where the blade will cut

Solid Steel Blade Carrier

Fine-Tuning Knob: Allows users to precisely adjust the back gauge position

Hydraulic Pressure Gauge Knob: Displays pressure and allows for easy adjustment of clamp pressure

Low-Friction Work Table: Makes it easy for operators to move and position large paper stacks

Internal Light: Illuminates the cutting area

Cutting Capacity: Paper stacks up to 3.15" high, up to 20.5" wide

Automatic Blade Return from Any Position

Programmable Jobs: Up to 100 jobs/100 steps

Foot Pedal Pre-Clamp: Holds paper stack in position to check alignment prior to cutting

Infrared Safety Curtain: Light beam curtain shuts down operation if the plane is interrupted

Two-Hand Operation: Electronically controlled for added safety

Easy Blade Change from Front of Cutter: Blade change safety tool included

Wooden Paper Push Tool: Helps to quickly and safely align the paper stack

Main Switch and Safety Key Lock: Keeps cutter secure from unauthorized operators

Transparent Rear Safety Guard

Options: Wide Side Tables (Pair) - Provide additional space to maneuver larger paper stock

Supplies: (29-10) Replacement Blade and (29-20) Replacement Cutting Sticks, pkg of 8

Compare to Similar Formax Guillotine Paper Cutters

Model Name

Model

Cutting Action

Maximum Cutting Width

Cutting Capacity

Maximum Paper Stack Height

Cutting Length Behind Blade

Length in Front of Blade

Programmable Jobs

Minimum Cut w/False Clamp

Minimum Cut w/o False Clamp

Narrow Cut

LED Laser Cut Line

Clamp Style

Back Gauge Adjustment

Back Gauge Reading

Blade Change Handles

Dimensions

Weight

Safety Certifications

Warranty
Cut-True 31H

Dual-button electric

28.7”

1000 Sheets

3.94”

26.5”

25”

Up to 100 programs with up to 100 steps each

2.36”

1.18”

N/A

N/A

Automatic, hydraulic

Fully programmable using touchscreen, accurate to 0.1mm

N/A

Included

73” W x 69” D x 56.9” H

1,323lbs.

N/A

90 day limited warranty on parts. Excluding wearables and labor.
Cut-True 31A

Dual-button hydraulic

28.7”

1000 Sheets

3.94”

26.5”

25”

Up to 100 programs with up to 100 steps each

2.36”

1.18”

N/A

N/A

Automatic, electronic

Fully programmable using touchscreen, accurate to 0.1mm

N/A

Included

73” W x 69” D x 56.9” H

1,279 lbs.

N/A

90 day limited warranty on parts. Excluding wearables and labor.
Cut-True 29H

Dual-button electric

20.5"

700 Sheets

3.15"

20.5"

18.25"

Up to 100 programs with up to 100 steps each

2.36”

1.18”

N/A

N/A

Automatic, hydraulic

Fully programmable using touchscreen, accurate to 0.1mm

N/A

Included

49.2" H x 36.75" W x 53.2" D

1,014 lbs.

N/A

90 day limited warranty on parts. Excluding wearables and labor.
Cut-True 29A

Dual-button electric

20.5"

700 Sheets

3.15"

20.5"

18.25"

Up to 100 programs with up to 100 steps each

2.36”

.98"

N/A

N/A

Automatic, electronically adjustablee

Fully programmable using touchscreen, accurate to 0.1mm

N/A

Included

49.2" H x 36.75" W x 53.2" D

683 lbs.

CE approved, UL pending

90 day limited warranty on parts. Excluding wearables and labor.
Cut-True 27S

Dual-button electric

18.9"

700 Sheets

3.15"

N/A

N/A

N/A

N/A

N/A

N/A

Yes

Automatic

Manual crank

Digital readout, in both inches and metric

Included

51" H x 36" W x 39" D

550 lbs.

CE approved, UL pending

90 day limited warranty on parts. Excluding wearables and labor.
Cut-True 22S

Dual-button electric

16.9"

440 Sheets

1.75"

N/A

N/A

N/A

N/A

N/A

N/A

Yes

Spindle-guided clamping wheel

Manual crank

Digital readout, in both inches and metric

Included

46.75" H x 24.75" W x 33" D

198.6 lbs.

CE approved, UL pending

90 day limited warranty on parts. Excluding wearables and labor.
Cut-True 16M

Manual lever handle

18.7"

700 Sheets

3.15"

N/A

N/A

N/A

N/A

N/A

N/A

Yes

Spindle-guided clamping wheel

Manual crank

Scale, in both inches and metric

Included

46.25" H x 39" W x 35" D

199 lbs.

CE approved

90 day limited warranty on parts. Excluding wearables and labor.
Cut-True 15M

Manual lever handle

16.9"

600 Sheets

2.15"

N/A

N/A

N/A

N/A

N/A

N/A

Yes

Spindle-guided clamping wheel

Manual crank

Scale, in both inches and metric

Included

42.5" H x 26.8" W x 29.1" D

133 lbs.

CE approved

90 day limited warranty on parts. Excluding wearables and labor.
Cut-True 13M

Manual lever handle

14.5"

370 Sheets

.75"

10.5"

1.25"

N/A

N/A

N/A

1.25"

Yes

Lever

Thumbscrew

Scale, in both inches and metric

Included

12.75" H x 18.75" W x 17.5" D

38 lbs.

CE approved

90 day limited warranty on parts. Excluding wearables and labor.

Resources

Fantastic Cutter

We were in need of a new cutter and due to our leased space, we had to have one the fits through a regular doorway. This cutter just made it (with the door removed) and it works like a charm. I would recommend this cutter to anyone needing a smaller sized machine. MyBinding.com was wonderful to work with and it was delivered in 5 business days.
